Toyota RAV4 (CHINA)
2013-08 → 2019-11 · chassis ASA4#,ZSA4# · catalogue 660320 · General
Discontinued model
Data version 2020-01
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 11711 — Bearing, Crankshaft | ||||
| 11701-0T031-01 note |
Bearing, Crankshaft
2013-08 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 11701-0T031-02 note |
Bearing, Crankshaft
2013-08 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 11701-0T031-03 note |
Bearing, Crankshaft
2013-08 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 11701-0T031-04 note |
Bearing, Crankshaft
2013-08 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 11711-0V040-01 note |
Bearing, Crankshaft
2013-08 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 11711-0V040-02 note |
Bearing, Crankshaft
2013-08 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 11711-0V040-03 note |
Bearing, Crankshaft
2013-08 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 11711-0V040-04 note |
Bearing, Crankshaft
2013-08 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 11701-0T070-01 note |
Bearing, Crankshaft
2018-05 → —
|
6ZRFAE ZSA4# | — | |
| 11701-0T070-02 note |
Bearing, Crankshaft
2018-05 → —
|
6ZRFAE ZSA4# | — | |
| 11701-0T070-03 note |
Bearing, Crankshaft
2018-05 → —
|
6ZRFAE ZSA4# | — | |
| 11701-0T070-04 note |
Bearing, Crankshaft
2018-05 → —
|
6ZRFAE ZSA4# | — | |
| 11701-37040-01 note |
Bearing, Crankshaft
2016-07 → 2018-05
ended
|
6ZRFAE ZSA4# | — | |
| 11701-37040-02 note |
Bearing, Crankshaft
2016-07 → 2018-05
ended
|
6ZRFAE ZSA4# | — | |
| 11701-37040-03 note |
Bearing, Crankshaft
2016-07 → 2018-05
ended
|
6ZRFAE ZSA4# | — | |
| 11701-37040-04 note |
Bearing, Crankshaft
2016-07 → 2018-05
ended
|
6ZRFAE ZSA4# | — | |
| 11711-0V050-01 note |
Bearing, Crankshaft
2017-11 → —
|
5ARFE ASA44 | — | |
| 11711-0V050-02 note |
Bearing, Crankshaft
2017-11 → —
|
5ARFE ASA44 | — | |
| 11711-0V050-03 note |
Bearing, Crankshaft
2017-11 → —
|
5ARFE ASA44 | — | |
| 11711-0V050-04 note |
Bearing, Crankshaft
2017-11 → —
|
5ARFE ASA44 | — | |
| 11711-36040-01 note |
Bearing, Crankshaft
2017-11 → —
|
5ARFE ASA44 | — | |
| 11711-36040-01 note |
Bearing, Crankshaft
2016-07 → —
|
2ARFE ASA45 | — | |
| 11711-36040-01 note |
Bearing, Crankshaft
2016-07 → 2017-11
ended
|
5ARFE ASA44 | — | |
| 11711-36040-02 note |
Bearing, Crankshaft
2016-07 → —
|
2ARFE ASA45 | — | |
| 11711-36040-02 note |
Bearing, Crankshaft
2017-11 → —
|
5ARFE ASA44 | — | |
| 11711-36040-02 note |
Bearing, Crankshaft
2016-07 → 2017-11
ended
|
5ARFE ASA44 | — | |
| 11711-36040-03 note |
Bearing, Crankshaft
2016-07 → —
|
2ARFE ASA45 | — | |
| 11711-36040-03 note |
Bearing, Crankshaft
2017-11 → —
|
5ARFE ASA44 | — | |
| 11711-36040-03 note |
Bearing, Crankshaft
2016-07 → 2017-11
ended
|
5ARFE ASA44 | — | |
| 11711-36040-04 note |
Bearing, Crankshaft
2017-11 → —
|
5ARFE ASA44 | — | |
| 11711-36040-04 note |
Bearing, Crankshaft
2016-07 → 2017-11
ended
|
5ARFE ASA44 | — | |
| 11711-36040-04 note |
Bearing, Crankshaft
2016-07 → —
|
2ARFE ASA45 | — | |
| 11791 — Washer, Crankshaft Thrust, Upper | ||||
| 11791-0T020 note |
Washer, Crankshaft Thrust, Upper
2013-08 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 11791-0V020 note |
Washer, Crankshaft Thrust, Upper
2013-08 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 11791-0V030 note |
Washer, Crankshaft Thrust, Upper
2017-11 → —
|
5ARFE ASA44 | — | |
| 11791-36010 note |
Washer, Crankshaft Thrust, Upper
2019-01 → —
|
2ARFE ASA45 | — | |
| 11791-36020 note |
Washer, Crankshaft Thrust, Upper
2016-07 → 2017-11
ended
|
5ARFE ASA44 | — | |
| 11791-36020 note |
Washer, Crankshaft Thrust, Upper
2017-11 → —
|
5ARFE ASA44 | — | |
| 11791-37010 note |
Washer, Crankshaft Thrust, Upper
2016-07 → —
|
6ZRFAE ZSA4# | — | |
| 13011 — Ring Set, Piston | ||||
| 13011-0T050 note |
Ring Set, Piston
2013-08 → 2015-05
ended
|
6ZRFE ZSA4# | — | |
| 13011-0T140 note |
Ring Set, Piston
2015-05 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 13011-0V020 note |
Ring Set, Piston
2013-08 → 2014-11
ended
|
5ARFE ASA44 | — | |
| 13011-0V070 note |
Ring Set, Piston
2014-11 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 13011-0T140 note |
Ring Set, Piston
2016-07 → —
|
6ZRFAE ZSA4# | — | |
| 13011-0T160 note |
Ring Set, Piston
2018-09 → —
|
6ZRFAE ZSA4# | — | |
| 13011-0V070 note |
Ring Set, Piston
2016-07 → —
|
5ARFE ASA44 | — | |
| 13011-36170 note |
Ring Set, Piston
2019-01 → —
|
2ARFE ASA45 | — | |
| 13041 — Bearing, Connecting Rod | ||||
| 13041-0T040-01 note |
Bearing, Connecting Rod
2013-08 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 13041-0T040-02 note |
Bearing, Connecting Rod
2013-08 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 13041-0T040-03 note |
Bearing, Connecting Rod
2013-08 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 13281-0V020-01 note |
Bearing, Connecting Rod
2013-08 → 2016-04
ended
|
5ARFE ASA44 | — | |
| 13281-0V020-02 note |
Bearing, Connecting Rod
2013-08 → 2016-04
ended
|
5ARFE ASA44 | — | |
| 13281-0V020-03 note |
Bearing, Connecting Rod
2013-08 → 2016-04
ended
|
5ARFE ASA44 | — | |
| 13281-0V021-01 note |
Bearing, Connecting Rod
2016-05 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 13281-0V021-02 note |
Bearing, Connecting Rod
2016-05 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 13281-0V021-03 note |
Bearing, Connecting Rod
2016-05 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 13041-0T040-01 note |
Bearing, Connecting Rod
2016-07 → —
|
6ZRFAE ZSA4# | — | |
| 13041-0T040-02 note |
Bearing, Connecting Rod
2016-07 → —
|
6ZRFAE ZSA4# | — | |
| 13041-0T040-03 note |
Bearing, Connecting Rod
2016-07 → —
|
6ZRFAE ZSA4# | — | |
| 13281-0V021-01 note |
Bearing, Connecting Rod
2016-07 → —
|
5ARFE ASA44 | — | |
| 13281-0V021-02 note |
Bearing, Connecting Rod
2016-07 → —
|
5ARFE ASA44 | — | |
| 13281-0V021-03 note |
Bearing, Connecting Rod
2016-07 → —
|
5ARFE ASA44 | — | |
| 13281-36021-01 note |
Bearing, Connecting Rod
2019-01 → —
|
2ARFE ASA45 | — | |
| 13281-36021-02 note |
Bearing, Connecting Rod
2019-01 → —
|
2ARFE ASA45 | — | |
| 13281-36021-03 note |
Bearing, Connecting Rod
2019-01 → —
|
2ARFE ASA45 | — | |
| 13101A — Ring, Hole Snap(FOR PISTON PIN) | ||||
| 90520-20064 |
Ring, Hole Snap(FOR PISTON PIN)
2013-08 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 90520-22025 |
Ring, Hole Snap(FOR PISTON PIN)
2013-08 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 90520-20064 |
Ring, Hole Snap(FOR PISTON PIN)
2016-07 → —
|
6ZRFAE ZSA4# | — | |
| 90520-22025 |
Ring, Hole Snap(FOR PISTON PIN)
2016-07 → —
|
2ARFE,5ARFE ASA4# | — | |
| 13201 — Rod Sub-assy, Connecting | ||||
| 13201-09A80-A0 note |
Rod Sub-assy, Connecting
2013-08 → 2016-05
ended
|
5ARFE ASA44 | — | |
| 13201-09A80-B0 note |
Rod Sub-assy, Connecting
2013-08 → 2016-05
ended
|
5ARFE ASA44 | — | |
| 13201-09A80-C0 note |
Rod Sub-assy, Connecting
2013-08 → 2016-05
ended
|
5ARFE ASA44 | — | |
| 13201-09A81-A0 note |
Rod Sub-assy, Connecting
2016-05 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 13201-09A81-B0 note |
Rod Sub-assy, Connecting
2016-05 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 13201-09A81-C0 note |
Rod Sub-assy, Connecting
2016-05 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 13201-39205 |
Rod Sub-assy, Connecting
2013-08 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 13201-09A81-A0 note |
Rod Sub-assy, Connecting
2016-07 → —
|
5ARFE ASA44 | — | |
| 13201-09A81-B0 note |
Rod Sub-assy, Connecting
2016-07 → —
|
5ARFE ASA44 | — | |
| 13201-09A81-C0 note |
Rod Sub-assy, Connecting
2016-07 → —
|
5ARFE ASA44 | — | |
| 13201-09D00 note |
Rod Sub-assy, Connecting
2017-01 → —
|
6ZRFAE ZSA4# | — | |
| 13201-39205 note |
Rod Sub-assy, Connecting
2016-07 → —
|
6ZRFAE ZSA4# | — | |
| 13201-39226-A0 note |
Rod Sub-assy, Connecting
2019-01 → —
|
2ARFE ASA45 | — | |
| 13201-39226-B0 note |
Rod Sub-assy, Connecting
2019-01 → —
|
2ARFE ASA45 | — | |
| 13201-39226-C0 note |
Rod Sub-assy, Connecting
2019-01 → —
|
2ARFE ASA45 | — | |
| 13201A — Bush(FOR CONNECTING ROD SMALL END) | ||||
| 90999-73151 |
Bush(FOR CONNECTING ROD SMALL END)
2013-08 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 90999-73151 |
Bush(FOR CONNECTING ROD SMALL END)
2016-07 → —
|
6ZRFAE ZSA4# | — | |
| 13211 — Piston | ||||
| 13211-0T110-A0 note |
Piston
2013-08 → 2015-05
ended
|
6ZRFE ZSA4# | — | |
| 13211-0T110-B0 note |
Piston
2013-08 → 2015-05
ended
|
6ZRFE ZSA4# | — | |
| 13211-0T110-C0 note |
Piston
2013-08 → 2015-05
ended
|
6ZRFE ZSA4# | — | |
| 13211-0T240-A0 note |
Piston
2015-05 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 13211-0T240-B0 note |
Piston
2015-05 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 13211-0T240-C0 note |
Piston
2015-05 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 13211-0V040-A0 note |
Piston
2013-08 → 2014-11
ended
|
5ARFE ASA44 | — | |
| 13211-0V040-B0 note |
Piston
2013-08 → 2014-11
ended
|
5ARFE ASA44 | — | |
| 13211-0V040-C0 note |
Piston
2013-08 → 2014-11
ended
|
5ARFE ASA44 | — | |
| 13211-0V090-A0 note |
Piston
2014-11 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 13211-0V090-B0 note |
Piston
2014-11 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 13211-0V090-C0 note |
Piston
2014-11 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 13211-0T100 |
Piston
2016-07 → —
|
6ZRFAE ZSA4# | — | |
| 13211-0T170 note |
Piston
2018-09 → —
|
6ZRFAE ZSA4# | — | |
| 13211-0V030-A0 note |
Piston
2016-07 → —
|
5ARFE ASA44 | — | |
| 13211-0V030-B0 note |
Piston
2016-07 → —
|
5ARFE ASA44 | — | |
| 13211-0V030-C0 note |
Piston
2016-07 → —
|
5ARFE ASA44 | — | |
| 13211-36090-A0 note |
Piston
2019-01 → —
|
2ARFE ASA45 | — | |
| 13211-36090-B0 note |
Piston
2019-01 → —
|
2ARFE ASA45 | — | |
| 13211-36090-C0 note |
Piston
2019-01 → —
|
2ARFE ASA45 | — | |
| 13251 — Pin, Piston | ||||
| 13251-0H040-A0 note |
Pin, Piston
2013-08 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 13251-0H040-B0 note |
Pin, Piston
2013-08 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 13251-0H040-C0 note |
Pin, Piston
2013-08 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 13251-0T010-A0 note |
Pin, Piston
2013-08 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 13251-0T010-B0 note |
Pin, Piston
2013-08 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 13251-0T010-C0 note |
Pin, Piston
2013-08 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 13251-0H040-A0 note |
Pin, Piston
2016-07 → —
|
5ARFE ASA44 | — | |
| 13251-0H040-B0 note |
Pin, Piston
2016-07 → —
|
5ARFE ASA44 | — | |
| 13251-0H040-C0 note |
Pin, Piston
2016-07 → —
|
5ARFE ASA44 | — | |
| 13251-0T010-A0 note |
Pin, Piston
2016-07 → —
|
6ZRFAE ZSA4# | — | |
| 13251-0T010-B0 note |
Pin, Piston
2016-07 → —
|
6ZRFAE ZSA4# | — | |
| 13251-0T010-C0 note |
Pin, Piston
2016-07 → —
|
6ZRFAE ZSA4# | — | |
| 13251-28020-A0 note |
Pin, Piston
2019-01 → —
|
2ARFE ASA45 | — | |
| 13251-28020-B0 note |
Pin, Piston
2019-01 → —
|
2ARFE ASA45 | — | |
| 13251-28020-C0 note |
Pin, Piston
2019-01 → —
|
2ARFE ASA45 | — | |
| 13265 — Bolt, Connecting Rod | ||||
| 13265-22020 |
Bolt, Connecting Rod
2013-08 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 13265-31020 |
Bolt, Connecting Rod
2013-08 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 13265-0T020 note |
Bolt, Connecting Rod
2018-03 → —
|
6ZRFAE ZSA4# | — | |
| 13265-0V010 note |
Bolt, Connecting Rod
2017-09 → —
|
5ARFE ASA44 | — | |
| 13265-22020 |
Bolt, Connecting Rod
2017-01 → 2018-03
ended
|
6ZRFAE ZSA4# | — | |
| 13265-22020 note |
Bolt, Connecting Rod
2016-07 → —
|
6ZRFAE ZSA4# | — | |
| 13265-31020 |
Bolt, Connecting Rod
2016-07 → —
|
2ARFE ASA45 | — | |
| 13265-31020 |
Bolt, Connecting Rod
2016-07 → 2017-09
ended
|
5ARFE ASA44 | — | |
| 13265-31020 note |
Bolt, Connecting Rod
2017-09 → —
|
5ARFE ASA44 | — | |
| 13405 — Flywheel Sub-assy | ||||
| 13405-0T060 |
Flywheel Sub-assy
2013-08 → 2016-07
ended
|
6ZRFE ZSA42 6F | — | |
| 13405A — Pin, Straight(FOR FLYWHEEL) | ||||
| 90250-C0011 note |
Pin, Straight(FOR FLYWHEEL)
2013-08 → 2016-07
ended
|
6ZRFE ZSA42 6F | — | |
| 13405B — Bolt, Flywheel Setting | ||||
| 90913-01027 |
Bolt, Flywheel Setting
2013-08 → 2016-07
ended
|
6ZRFE ZSA42 6F | — | |
| 13411 — Crankshaft | ||||
| 13401-0V021 |
Crankshaft
2013-08 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 13401-37032 |
Crankshaft
2013-09 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 13401-0T080 note |
Crankshaft
2017-01 → —
|
6ZRFAE ZSA4# | — | |
| 13401-0V060 |
Crankshaft
2016-07 → 2019-01
ended
|
5ARFE ASA44 | — | |
| 13401-36110 |
Crankshaft
2019-01 → —
|
2ARFE,5ARFE ASA4# | — | |
| 13401-37032 note |
Crankshaft
2017-01 → —
|
6ZRFAE ZSA4# | — | |
| 13401-37032 |
Crankshaft
2016-07 → 2017-01
ended
|
6ZRFAE ZSA4# | — | |
| 13453 — Gear, Flywheel Ring | ||||
| 13453-0T060 |
Gear, Flywheel Ring
2013-08 → 2016-07
ended
|
6ZRFE ZSA42 6F | — | |
| 13471 — Pulley, Crankshaft | ||||
| 13470-0T010 |
Pulley, Crankshaft
2013-08 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 13470-0V030 |
Pulley, Crankshaft
2013-08 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 13470-0T040 |
Pulley, Crankshaft
2016-07 → —
|
6ZRFAE ZSA4# | — | |
| 13470-0V030 |
Pulley, Crankshaft
2016-07 → —
|
5ARFE ASA44 | — | |
| 13470-36010 |
Pulley, Crankshaft
2019-01 → —
|
2ARFE ASA45 | — | |
| 13471C — Bolt(FOR CRANKSHAFT PULLEY SET) | ||||
| 90119-16020 |
Bolt(FOR CRANKSHAFT PULLEY SET)
2013-08 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 90119-C0124 |
Bolt(FOR CRANKSHAFT PULLEY SET)
2013-08 → 2015-04
ended
|
6ZRFE ZSA4# | — | |
| 90119-C0499 |
Bolt(FOR CRANKSHAFT PULLEY SET)
2015-05 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 90119-16020 |
Bolt(FOR CRANKSHAFT PULLEY SET)
2016-07 → —
|
2ARFE ASA45 | — | |
| 90119-16020 note |
Bolt(FOR CRANKSHAFT PULLEY SET)
2017-02 → —
|
5ARFE ASA44 | — | |
| 90119-16020 |
Bolt(FOR CRANKSHAFT PULLEY SET)
2016-07 → 2017-02
ended
|
5ARFE ASA44 | — | |
| 90119-C0124 |
Bolt(FOR CRANKSHAFT PULLEY SET)
2018-10 → —
|
6ZRFAE ZSA4# | — | |
| 90119-C0429 note |
Bolt(FOR CRANKSHAFT PULLEY SET)
2017-02 → —
|
5ARFE ASA44 | — | |
| 90119-C0499 |
Bolt(FOR CRANKSHAFT PULLEY SET)
2016-07 → 2018-09
ended
|
6ZRFAE ZSA4# | — | |
| 13519 — Gear, Oil Pump Drive | ||||
| 13519-0T010 |
Gear, Oil Pump Drive
2013-08 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 13519-0T010 |
Gear, Oil Pump Drive
2016-07 → —
|
6ZRFAE ZSA4# | — | |
| 13521 — Gear OR Sprocket, Crankshaft Timing | ||||
| 13521-0T100 |
Gear OR Sprocket, Crankshaft Timing
2016-06 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 13521-0V020 |
Gear OR Sprocket, Crankshaft Timing
2013-08 → 2016-07
ended
|
5ARFE ASA44 | — | |
| 13521-37020 |
Gear OR Sprocket, Crankshaft Timing
2013-08 → 2016-06
ended
|
6ZRFE ZSA4# | — | |
| 13521-0T100 |
Gear OR Sprocket, Crankshaft Timing
2016-07 → —
|
6ZRFAE ZSA4# | — | |
| 13521-0V020 |
Gear OR Sprocket, Crankshaft Timing
2016-07 → —
|
5ARFE ASA44 | — | |
| 13521-36010 |
Gear OR Sprocket, Crankshaft Timing
2019-01 → —
|
2ARFE ASA45 | — | |
| 13521A — Key(FOR CRANKSHAFT TIMING GEAR) | ||||
| 90280-04003 |
Key(FOR CRANKSHAFT TIMING GEAR)
2013-09 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 90280-04003 |
Key(FOR CRANKSHAFT TIMING GEAR)
2016-07 → —
|
6ZRFAE ZSA4# | — | |
| 19315 — Plate, Crank Angle Sensor, NO.1 | ||||
| 19315-0T020 |
Plate, Crank Angle Sensor, NO.1
2014-09 → 2016-07
ended
|
6ZRFE ZSA4# | — | |
| 19315-37020 |
Plate, Crank Angle Sensor, NO.1
2013-08 → 2014-09
ended
|
6ZRFE ZSA4# | — | |
| 19315-0T010 |
Plate, Crank Angle Sensor, NO.1
2016-07 → —
|
6ZRFAE ZSA4# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
