Toyota RAV4 (CHINA)
2013-08 → 2019-11 · chassis ASA4#,ZSA4# · catalogue 660320 · General
Discontinued model
Data version 2020-01
Instrument Panel & Glove Compartment
49 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 55012A | Garnish Sub-assy, Instrument Panel, NO.2 |
| 55045A | Panel Sub-assy, Instrument Panel Finish, Lower RH |
| 55054 | Stopper Sub-assy, Glove Compartment Door |
| 55302A | Panel Sub-assy, Instrument, Upper |
| 55306A | Brace Sub-assy, Instrument Panel, NO.1 |
| 55307C | Brace Sub-assy, Instrument Panel, NO.2 |
| 55312 | Panel, Instrument, Lower |
| 55317A | Panel, Instrument Side, RH |
| 55328A | Stay, Instrument Panel, NO.3 |
| 55331 | Reinforcement, Instrument Panel |
| 55382 | Bracket, Finish Panel Mounting, NO.2 |
| 55389 | Bracket, Console Mounting, LH |
| 55394D | Cover, Instrument Panel Bracket, Inner NO.1 RH |
| 55395C | Cover, Instrument Panel Bracket, Inner NO.1 LH |
| 55406B | Panel Sub-assy, Instrument Cluster Finish, Lower Center |
| 55411G | Panel, Instrument Cluster Finish, NO.1 |
| 55412C | Panel, Instrument Cluster Finish, Center NO.1 |
| 55416C | Retainer, Instrument Cluster Finish Panel |
| 55417A | Retainer, Meter Hood, NO.2 |
| 55418B | Spacer,Meter Hood |
| 55421B | Panel, Instrument Cluster Finish, Upper |
| 55432B | Panel, Instrument Panel Finish, Lower |
| 55433B | Panel, Instrument Panel Finish, Lower NO.2 |
| 55434B | Panel, Instrument Panel Finish, Lower Center |
| 55447C | Base, Switch Hole, NO.2 |
| 55453D | Pad, Instrument Panel Safety, NO.1 |
| 55454B | Pad, Instrument Panel Safety, NO.2 |
| 55474B | Garnish, Instrument Cluster Finish Panel |
| 55476C | Garnish, Instrument Panel Finish Plate |
| 55501A | Door Sub-assy, Glove Compartment |
| 55525 | Cover, Speaker Hole, NO.1 |
| 55535B | Cover, Speaker Hole, NO.2 |
| 55539 | Cover, Spare Switch Hole |
| 55539C | Cover, Spare Switch Hole |
| 55545 | Cover, Fuse Box Opening |
| 55549B | Cover, Instrument Panel Hole, NO.2 |
| 55550 | Door Assy, Glove Compartment |
| 55557A | Cushion, Glove Compartment Door Check |
| 55606 | Cover Sub-assy, Instrument Panel Under, NO.1 |
| 55607 | Cover Sub-assy, Instrument Panel Under, NO.2 |
| 55650 | Register Assy, Instrument Panel, NO.1 |
| 55660C | Register Assy, Instrument Panel |
| 55670 | Register Assy, Instrument Panel, NO.3 |
| 55680A | Register Assy, Instrument Panel, NO.4 |
| 55833C | Connector, Instrument Panel Register, Center |
| 58917B | Mat, Box Bottom |
| 73900 | Airbag Assy, Instrument Panel, Lower NO.1 |
| 73960A | Airbag Assy, Instrument Panel Passenger W/O Door |
| 73990 | Airbag Assy, Instrument Panel, Lower NO.2 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
