Toyota Wildlander (GTMC)
2020-04 → present · chassis AXAH5#,AXAL5#,MXAA5# · catalogue 664330 · General
Supported model
Data version 2024-04
Floor Mat & Silencer Pad
19 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 55213B | Pad, Dash Panel Insulator, NO.1 |
| 55214C | Pad, Dash Panel Insulator, NO.2 |
| 55215D | Pad, Dash Panel Insulator, NO.3 |
| 58441J | Cover, Battery Service Hole |
| 58441N | Clip(FOR BATTERY SERVICE HOLE COVER) |
| 58464D | Board, Battery Service Cover |
| 58466J | Board, Battery Service Cover, NO.2 |
| 58467H | Board, Battery Service Cover, NO.3 |
| 58510C | Carpet Assy, Front Floor, Front |
| 58510H | Mat Assy, Floor |
| 58511E | Clip(FOR FRONT FLOOR MAT) |
| 58511K | Mat, Floor, NO.1 |
| 58512J | Mat, Floor, NO.2 |
| 58520C | Clip(FOR FRONT FLOOR CARPET) |
| 58521B | Hook, Floor Carpet |
| 58569D | Cover, Front Floor Caution Plate |
| 58571D | Mat, Rear Floor, Front RH |
| 58694A | Plate, Mat Set, Upper |
| 58698B | Plate, Mat Set, Lower |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
