Toyota Wildlander (GTMC)

2020-04 → present · chassis AXAH5#,AXAL5#,MXAA5# · catalogue 664330 · General

Supported model Data version 2024-04

Back Door Panel & Glass

38 part groups · 2 illustrations

PNC	Description
62785F	Spacer, Back Door Glass
64818B	Spacer, Back Door Glass, NO.1
64819	Spacer, Back Window Glass, NO.2
67005	Panel Sub-assy, Back Door
67372A	Weight, Back Door
67750	Board Assy, Back Door Trim
67750A	Clip(FOR BACK DOOR TRIM)
67751A	Clip(FOR BACK DOOR TRIM BOARD)
67766	Cover, Back Door Service Hole, NO.2
67816D	Sheet, Back Door Panel Silencer
67837L	Seal, Door Dust Proof
67837N	Seal, Back Door Dust Proof
67847	Cover, Back Door Service Hole, RH
67848C	Cover, Back Door Service Hole, NO.2
67881A	Weatherstrip, Back Door
67937B	Garnish, Back Door Side, RH
67937C	Clip(FOR BACK DOOR SIDE GARNISH)
67938A	Garnish, Back Door Side, LH
67939B	Garnish, Back Door, Center
67939C	Clip(FOR BACK DOOR CENTER GARNISH)
68131	Glass, Back Door
68294B	Dam, Back Door Glass Adhesive
69195A	Grip, Back Door
69196	Base, Back Door Grip
69478A	Cushion, Back Door Lower Stopper
75126A	Plate, Rear License Plate Bracket Support
75575D	Moulding, Back Window, Lower
76801	Garnish Sub-assy, Back Door, Outside
76802E	Garnish Sub-assy, Back Door, Outside Lower
76815C	Moulding, Back Door Outside Garnish, Lwr RH
76816B	Moulding, Back Door Outside Garnish, Lwr LH
76817	Clip, Back Door Outside Garnish
76821	Protector, Back Door Garnish Moulding, Upper
76822A	Protector, Back Door Garnish Moulding, Lwr
76823	Protector, Back Door Garnish Moulding, RH
76825	Protector, Back Door Outside Garnish
76881B	Protector, Back Door Lower Moulding, RH
76882B	Protector, Back Door Lower Moulding, LH

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
