Toyota Hilux/4Runner (4WD)
1988-08 → 2004-12 · chassis LN,RN,YN,VZN10#,11#,13#,KZN,LN205 · catalogue 671350 · General
Discontinued model
Data version 2005-07
Accelerator Link
18 part groups · 11 illustrations
Part groups
| PNC | Description |
|---|---|
| 78010A | Bush (FOR ACCELERATOR LINK) |
| 78024 | Bracket Sub-assy, Accelerator Control Cable |
| 78100 | Link Assy, Accelerator |
| 78104 | Rod Sub-assy, Accelerator Connecting, NO.2 |
| 78111 | Pedal, Accelerator |
| 78111C | Pin (FOR ACCELERATOR PEDAL) |
| 78120G | Rod Assy, Accelerator Pedal |
| 78130 | Bellcrank Assy, Accelerator |
| 78130B | Bush, Accelerator Bellcrank |
| 78157 | Ball, Accelerator Joint |
| 78160A | Bellcrank Assy, Accel Control W/Bracket |
| 78166 | Bracket, Accel Control NO.2 Bellcrank |
| 78180P | Cable Assy, Accelerator Control |
| 78184B | Bracket, Accelerator Control Cable |
| 78186A | Clamp, Accelerator Control Cable, NO.3 |
| 78401 | Cable Sub-assy, Throttle Control |
| 78411A | Knob, Throttle Control Cable |
| 78472 | Support, Throttle Control Cable |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
