Toyota Fortuner
2005-01 → 2012-04 · chassis GGN50,60,KUN5#,6#,LAN50,TGN51,61 · catalogue 671380 · General
Supported model
Data version 2012-04
Back Door Panel & Glass
26 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 64795A | Trim, Back Window Opening |
| 64818B | Spacer, Back Door Glass, NO.1 |
| 64819 | Spacer, Back Window Glass, NO.2 |
| 64819B | Spacer, Back Window Glass, NO.2 |
| 64827A | Clip, Back Window Glass, RH |
| 64828 | Clip, Back Window Glass, LH |
| 64885C | Channel, Back Door Glass, RH |
| 64886B | Channel, Back Door Glass, LH |
| 67005 | Panel Sub-assy, Back Door |
| 67152A | Cover, Back Door Service Hole |
| 67750 | Board Assy, Back Door Trim |
| 67751A | Clip(FOR BACK DOOR TRIM BOARD) |
| 67837L | Seal, Door Dust Proof |
| 67848F | Cover, Back Door Service Hole, NO.2 |
| 67881A | Weatherstrip, Back Door |
| 68131 | Glass, Back Door |
| 68294A | Dam, Back Door Glass Adhesive |
| 68294B | Dam, Back Door Glass Adhesive |
| 74811G | Handle, Door Pull |
| 75129C | Cushion, Rear Licence Plate |
| 76811A | Garnish, Back Door, Outside |
| 76817 | Clip, Back Door Outside Garnish |
| 76818 | Pad, Back Door Outside Garnish |
| 76821 | Protector, Back Door Garnish Moulding, Upper |
| 76822A | Protector, Back Door Garnish Moulding, Lwr |
| 76825 | Protector, Back Door Outside Garnish |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
