Toyota Fortuner
2015-07 → 2021-04 · chassis GGN155,165,GUN15#,16#,KUN156,165,LAN155,TGN156,16# · catalogue 6713B0 · General
Supported model
Data version 2022-11
Seat Belt
34 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 73023 | Plate Sub-assy, Front Shoulder Belt Anchor, RH |
| 73024 | Plate Sub-assy, Front Shoulder Belt Anchor, LH |
| 73119 | Plate, Seat Belt Webbing Clip |
| 73135A | Cover, Shoulder Belt Anchor, RH |
| 73136A | Cover, Shoulder Belt Anchor, LH |
| 73139C | Cover, Rear Seat Belt |
| 73178A | Cap, Seat Belt Anchor Cover |
| 73178C | Cap, Seat Belt Anchor Cover |
| 73200A | Adjuster Assy, Front Shoulder Belt Anchor |
| 73210 | Belt Assy, Front Seat Outer, RH |
| 73219 | Stopper, Tongue Plate |
| 73220 | Belt Assy, Front Seat Outer, LH |
| 73230 | Belt Assy, Front Seat Inner, RH |
| 73233 | Cover, Lap Belt Outer Anchor |
| 73233A | Cover, Lap Belt Outer Anchor, Rear NO.1 Seat |
| 73233B | Cover, Lap Belt Outer Anchor, Rear NO.2 Seat |
| 73240 | Belt Assy, Front Seat Inner, LH |
| 73310D | Belt Assy, Rear Seat 3 Point Type, Center |
| 73330C | Belt Assy, Rear Seat Lap Type, Center RH |
| 73340C | Belt Assy, Rear Seat Lap Type, Center LH |
| 73345 | Guide, Rear Seat Shoulder Belt, Center |
| 73360C | Belt Assy, Rear NO.1 Seat, Outer RH |
| 73370C | Belt Assy, Rear NO.1 Seat, Outer LH |
| 73371A | Hanger Rear Seat Shoulder Belt |
| 73380 | Belt Assy, Rear Seat 3 Point Type, Inner, RH |
| 73381 | Holder, Rear Seat Belt |
| 73560 | Belt Assy, Rear NO.2 Seat, Outer RH |
| 73570 | Belt Assy, Rear NO.2 Seat, Outer LH |
| 73580A | Belt Sub Assy, Rear NO.2 Seat, Inner |
| 73590A | Belt Assy, Rear Seat, Inner LH |
| 73711A | Body, Child Restraint Seat |
| 73716 | Protector, Child Restraint Seat |
| 73717 | Cover, Child Restraint Seat Tether Anchor |
| 73719 | Bracket, Child Restraint Seat Tether Anchor |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
