Toyota Fortuner (SUV)
2022-08 → present · chassis GGN155,GUN15#,16#,LAN155,TGN156,166 · catalogue 6713E0 · General
Supported model
Data version 2024-07
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 25712A — Wire, Emission Control Valve | ||||
| 25712-0E010 note |
Wire, Emission Control Valve
2022-11 → 2023-05
ended
|
2GDFTV GUN165 L LA;1GDFTV +3 | — | |
| 25712-0E010 note |
Wire, Emission Control Valve
2022-08 → 2023-07
ended
|
1GDFTV,2GDFTV GUN15#,16# THP | — | |
| 25712-0E010 note |
Wire, Emission Control Valve
2022-08 → —
|
1GDFTV GUN156 PKNP | — | |
| 25712-0E010 note |
Wire, Emission Control Valve
2022-08 → 2023-08
ended
|
1GDFTV,2GDFTV GUN15#,16# IDNP,MAP | — | |
| 25712-0E010 note |
Wire, Emission Control Valve
2022-08 → 2023-09
ended
|
1GDFTV,2GDFTV GUN156,165 VNP | — | |
| 25712-0E010 note |
Wire, Emission Control Valve
2022-08 → 2023-10
ended
|
1GDFTV,2GDFTV GUN156,16# AGTP | — | |
| 25712-0E010 note |
Wire, Emission Control Valve
2022-08 → 2024-01
ended
|
1GDFTV,2GDFTV GUN15#,16# SA | — | |
| 25712-0E010 note |
Wire, Emission Control Valve
2022-08 → 2024-03
ended
|
1GDFTV,2GDFTV GUN15# KEN | — | |
| 25712-0E020 note |
Wire, Emission Control Valve
2022-08 → 2023-07
ended
|
1GDFTV GUN156 THP ARL | — | |
| 25712-0E020 note |
Wire, Emission Control Valve
2022-08 → 2023-09
ended
|
1GDFTV GUN156,166 IND | — | |
| 25712-11010 note |
Wire, Emission Control Valve
2022-08 → 2023-05
ended
|
2GDFTV GUN155 THP GCC | — | |
| 25712-11010 note |
Wire, Emission Control Valve
2022-08 → 2023-05
ended
|
2GDFTV GUN155 THP S | — | |
| 25712-11010 note |
Wire, Emission Control Valve
2022-08 → 2023-07
ended
|
2GDFTV GUN155,165 THP | — | |
| 26100G — Body Assy, Diesel Throttle | ||||
| 26100-0E050 note |
Body Assy, Diesel Throttle
2022-08 → —
|
1GDFTV GUN156 PKNP | — | |
| 26100-0E050 note |
Body Assy, Diesel Throttle
2022-08 → 2024-03
ended
|
1GDFTV,2GDFTV GUN15# KEN | — | |
| 26100-0E050 note |
Body Assy, Diesel Throttle
2022-08 → 2024-01
ended
|
1GDFTV,2GDFTV GUN15#,16# SA | — | |
| 26100-0E050 note |
Body Assy, Diesel Throttle
2022-08 → 2023-10
ended
|
1GDFTV,2GDFTV GUN156,16# AGTP | — | |
| 26100-0E050 note |
Body Assy, Diesel Throttle
2022-08 → 2023-09
ended
|
1GDFTV,2GDFTV GUN156,16# INDP,VNP | — | |
| 26100-0E050 note |
Body Assy, Diesel Throttle
2022-08 → 2023-08
ended
|
1GDFTV,2GDFTV GUN15#,16# IDNP,MAP | — | |
| 26100-0E050 note |
Body Assy, Diesel Throttle
2022-08 → 2023-07
ended
|
1GDFTV,2GDFTV GUN15#,16# THP | — | |
| 26100-0E050 note |
Body Assy, Diesel Throttle
2022-11 → 2023-05
ended
|
2GDFTV GUN165 L LA;1GDFTV +3 | — | |
| 26100-0E060 note |
Body Assy, Diesel Throttle
2022-08 → 2023-07
ended
|
1GDFTV GUN156 THP ARL | — | |
| 26100-0E060 note |
Body Assy, Diesel Throttle
2022-08 → 2023-09
ended
|
1GDFTV GUN156,166 IND | — | |
| 26100-11040 note |
Body Assy, Diesel Throttle
2022-08 → 2023-05
ended
|
2GDFTV GUN155 THP GCC | — | |
| 26100-11040 note |
Body Assy, Diesel Throttle
2022-08 → 2023-05
ended
|
2GDFTV GUN155 THP S | — | |
| 26100-11040 note |
Body Assy, Diesel Throttle
2022-08 → 2023-07
ended
|
2GDFTV GUN155,165 THP | — | |
| 26171 — Gasket, Venturi | ||||
| 17116-54030 |
Gasket, Venturi
2023-01 → —
|
5LE LAN155 | — | |
| 26171-0E030 note |
Gasket, Venturi
2022-11 → 2023-05
ended
|
2GDFTV GUN165 L LA;1GDFTV +3 | — | |
| 26171-0E030 note |
Gasket, Venturi
2022-08 → 2023-07
ended
|
1GDFTV,2GDFTV GUN15#,16# THP | — | |
| 26171-0E030 note |
Gasket, Venturi
2022-08 → 2023-08
ended
|
1GDFTV,2GDFTV GUN15#,16# IDNP,MAP | — | |
| 26171-0E030 note |
Gasket, Venturi
2022-08 → 2023-09
ended
|
1GDFTV,2GDFTV GUN156,16# INDP,VNP | — | |
| 26171-0E030 note |
Gasket, Venturi
2022-08 → 2023-10
ended
|
1GDFTV,2GDFTV GUN156,16# AGTP | — | |
| 26171-0E030 note |
Gasket, Venturi
2022-08 → 2024-01
ended
|
1GDFTV,2GDFTV GUN15#,16# SA | — | |
| 26171-0E030 note |
Gasket, Venturi
2022-08 → 2024-03
ended
|
1GDFTV,2GDFTV GUN15# KEN | — | |
| 26171-0E030 note |
Gasket, Venturi
2022-08 → —
|
1GDFTV GUN156 PKNP | — | |
| 26171-0E040 note |
Gasket, Venturi
2022-08 → 2023-07
ended
|
1GDFTV GUN156 THP ARL | — | |
| 26171-0E040 note |
Gasket, Venturi
2022-08 → 2023-09
ended
|
1GDFTV GUN156,166 IND | — | |
| 26171-11020 note |
Gasket, Venturi
2022-08 → 2023-05
ended
|
2GDFTV GUN155 THP GCC | — | |
| 26171-11020 note |
Gasket, Venturi
2022-08 → 2023-07
ended
|
2GDFTV GUN155,165 THP | — | |
| 26171-11020 note |
Gasket, Venturi
2022-08 → 2023-05
ended
|
2GDFTV GUN155 THP S | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
