Toyota Fortuner (SUV)
2022-08 → present · chassis GGN155,GUN15#,16#,LAN155,TGN156,166 · catalogue 6713E0 · General
Supported model
Data version 2024-07
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 89421C — Sensor, Turbo Pressure (FOR DIESEL TURBO) | ||||
| 89421-12150 |
Sensor, Turbo Pressure (FOR DIESEL TURBO)
2023-01 → 2024-01
ended
|
LAN155 | — | |
| 89421-71030 |
Sensor, Turbo Pressure (FOR DIESEL TURBO)
2022-08 → 2023-08
ended
|
GUN165 IDNP;GUN165 VNP L;GUN15#,166 +1 | — | |
| 89421-71030 |
Sensor, Turbo Pressure (FOR DIESEL TURBO)
2022-08 → 2023-09
ended
|
GUN165 VNP 6FC | — | |
| 89421-71030 note |
Sensor, Turbo Pressure (FOR DIESEL TURBO)
2023-08 → 2023-09
ended
|
GUN165 VNP L | — | |
| 89421-71030 |
Sensor, Turbo Pressure (FOR DIESEL TURBO)
2022-08 → 2023-10
ended
|
GUN165 LA | — | |
| 89421-71030 note |
Sensor, Turbo Pressure (FOR DIESEL TURBO)
2023-08 → 2023-10
ended
|
GUN166 6FC LA | — | |
| 89421-71030 note |
Sensor, Turbo Pressure (FOR DIESEL TURBO)
2023-08 → 2023-10
ended
|
GUN156 6F LA | — | |
| 89421-71030 |
Sensor, Turbo Pressure (FOR DIESEL TURBO)
2022-08 → 2024-01
ended
|
GUN15#,16# SA | — | |
| 89421-71030 |
Sensor, Turbo Pressure (FOR DIESEL TURBO)
2022-08 → 2024-03
ended
|
GUN15# KEN | — | |
| 89421-71030 |
Sensor, Turbo Pressure (FOR DIESEL TURBO)
2022-08 → —
|
GUN156 PKNP | — | |
| 89421-71030 |
Sensor, Turbo Pressure (FOR DIESEL TURBO)
2022-08 → 2023-07
ended
|
GUN15#,16# THP | — | |
| 89422C — Sensor, Diesel Engine Water Temperature | ||||
| 89422-33030 note |
Sensor, Diesel Engine Water Temperature
2023-08 → 2023-10
ended
|
GUN166 6FC LA | — | |
| 89422-33030 |
Sensor, Diesel Engine Water Temperature
2022-08 → —
|
GUN156 PKNP | — | |
| 89422-33030 |
Sensor, Diesel Engine Water Temperature
2022-08 → 2024-03
ended
|
GUN15# KEN | — | |
| 89422-33030 |
Sensor, Diesel Engine Water Temperature
2022-08 → 2024-01
ended
|
GUN15#,16#,LAN155 SA | — | |
| 89422-33030 note |
Sensor, Diesel Engine Water Temperature
2023-08 → 2023-10
ended
|
GUN156 6F LA | — | |
| 89422-33030 note |
Sensor, Diesel Engine Water Temperature
2023-08 → 2023-09
ended
|
GUN165 VNP L | — | |
| 89422-33030 |
Sensor, Diesel Engine Water Temperature
2022-08 → 2023-09
ended
|
GUN165 VNP 6FC | — | |
| 89422-33030 |
Sensor, Diesel Engine Water Temperature
2022-08 → 2023-08
ended
|
GUN165 IDNP;GUN165 VNP L;GUN15#,166 +1 | — | |
| 89422-33030 |
Sensor, Diesel Engine Water Temperature
2022-08 → 2023-07
ended
|
GUN15#,16# THP | — | |
| 89422-33030 |
Sensor, Diesel Engine Water Temperature
2022-08 → 2023-10
ended
|
GUN165 LA | — | |
| 89424D — Sensor, Inlet Air Temperature | ||||
| 89424-12010 |
Sensor, Inlet Air Temperature
2023-01 → 2024-01
ended
|
LAN155 | — | |
| 89424-60010 note |
Sensor, Inlet Air Temperature
2023-08 → 2023-09
ended
|
GUN165 VNP L | — | |
| 89424-60010 |
Sensor, Inlet Air Temperature
2022-08 → —
|
GUN156 PKNP | — | |
| 89424-60010 |
Sensor, Inlet Air Temperature
2022-08 → 2024-03
ended
|
GUN15# KEN | — | |
| 89424-60010 |
Sensor, Inlet Air Temperature
2022-08 → 2024-01
ended
|
GUN15#,16# SA | — | |
| 89424-60010 note |
Sensor, Inlet Air Temperature
2023-08 → 2023-10
ended
|
GUN156 6F LA | — | |
| 89424-60010 note |
Sensor, Inlet Air Temperature
2023-08 → 2023-10
ended
|
GUN166 6FC LA | — | |
| 89424-60010 |
Sensor, Inlet Air Temperature
2022-08 → 2023-10
ended
|
GUN165 LA | — | |
| 89424-60010 |
Sensor, Inlet Air Temperature
2022-08 → 2023-09
ended
|
GUN165 VNP 6FC | — | |
| 89424-60010 |
Sensor, Inlet Air Temperature
2022-08 → 2023-08
ended
|
GUN165 IDNP;GUN165 VNP L;GUN15#,166 +1 | — | |
| 89424-60010 |
Sensor, Inlet Air Temperature
2022-08 → 2023-07
ended
|
GUN15#,16# THP | — | |
| 89454 — Sensor, Fuel Temperature | ||||
| 89454-60010 |
Sensor, Fuel Temperature
2023-01 → 2024-01
ended
|
LAN155 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
