Toyota Hilux Champ

2023-12 → present · chassis GUN1##,TGN11# · catalogue 676210 · General

Supported model Data version 2023-11
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Hood & Front Fender

12 part groups · 2 illustrations

Illustrations

Figure 53903MA 53903MA 2023-12 → — Figure 53903NA 53903NA 2023-12 → —

Part groups

PNCDescription
47749D Clip, Pin Hold
53301 Hood Sub-assy
53381A Clip(FOR HOOD TO RADIATOR SUPPORT SEAL)
53801 Fender Sub-assy, Front RH
53802 Fender Sub-assy, Front LH
53875A Liner, Front Fender, RH
53875C Clip, Front Fender Liner
53875P Screw, NO.1
53876A Liner, Front Fender, LH
53882K Seal, Front Fender
53941 Extension, Front End Panel, NO.1 RH
53942 Extension, Front End Panel, NO.1 LH
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
