Toyota Alphard/Vellfire/HV
2008-04 → 2015-01 · chassis ANH20,ATH20,GGH20 · catalogue 713230 · General
Supported model
Data version 2015-01
Inside Trim Board
71 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 55973A | Duct, Side Defroster Nozzle, NO.3 |
| 55974A | Duct, Side Defroster Nozzle, NO.4 |
| 62111B | Clip(FOR COWL SIDE TRIM) |
| 62111C | Board, Cowl Side Trim, RH |
| 62112 | Board, Cowl Side Trim, LH |
| 62117B | Clip, NO.1(FOR COWL SIDE TRIM) |
| 62117C | Clip, NO.2(FOR COWL SIDE TRIM) |
| 62170A | Airbag Assy, Curtain Shield, RH |
| 62170B | Bolt, W/Washer |
| 62180A | Airbag Assy, Curtain Shield, LH |
| 62211 | Garnish, Front Pillar, RH |
| 62211T | Clip(FOR FRONT PILLAR GARNISH) |
| 62212 | Garnish, Front Pillar, LH |
| 62213 | Pad, Front Pillar Garnish |
| 62217H | Clip, Center Piller Garnish |
| 62225A | Garnish, Front Pillar, Lower RH |
| 62226 | Garnish, Front Pillar, Lower LH |
| 62401A | Clip (FOR CENTER PILLAR GARNISH PANEL, UPPER) |
| 62411B | Garnish, Center Pillar, Upper RH |
| 62412B | Garnish, Center Pillar, Upper LH |
| 62413A | Garnish, Center Pillar, Lower RH |
| 62413C | Clip (FOR CENTER LOWER GARNISH) |
| 62414A | Garnish, Center Pillar, Lower LH |
| 62430A | Clip, Roof Side Rail Garnish |
| 62431C | Garnish, Roof Side Rail, Front RH |
| 62432C | Garnish, Roof Side Rail, Front LH |
| 62451A | Clip, Side Garnish |
| 62451C | Garnish, Roof Side Rail, Rear RH |
| 62452C | Garnish, Roof Side Rail, Rear LH |
| 62471E | Garnish, Roof Side, Inner Upper RH |
| 62471J | Clip (FOR ROOF SIDE GARNISH) |
| 62472E | Garnish, Roof Side, Inner Upper LH |
| 62472G | Clip (FOR ROOF SIDE GARNISH) |
| 62475G | Seal, Roof Side, Inner |
| 62531A | Spacer, Quarter Trim, RH |
| 62532A | Spacer, Quarter Trim, LH |
| 62566A | Cover, Rear Pillar, RH |
| 62567B | Cover, Rear Pillar, LH |
| 62571D | Garnish, Quarter Lock Pillar, RH |
| 62572D | Garnish, Quarter Lock Pillar, LH |
| 62581F | Clip (FOR QUARTER PILLAR GARNISH) |
| 62627B | Cover, Quarter Trim |
| 62628B | Cover, Quarter Trim, LH |
| 62630K | Clip(FOR QUARTER TRIM REAR PANEL) |
| 62630P | Panel Assy, Quarter Trim, Rear RH |
| 62633C | Clip (FOR QUARTER TRIM GARNISH) |
| 62640K | Clip(FOR QUARTER TRIM REAR PANEL) |
| 62640P | Panel Assy, Quarter Trim, Rear LH |
| 62681A | Ornament, Quarter Trim, RH |
| 62682 | Ornament, Quarter Trim, LH |
| 64715C | Cover, Deck Side Trim, LH |
| 64721J | Cover, Luggage Compartment Trim, Inner RH |
| 64722C | Cover, Luggage Compartment Trim, Inner LH |
| 64725F | Hook, Luggage Compartment Trim, NO.1 |
| 64726F | Hook, Luggage Compartment Trim, NO.2 |
| 64735F | Cover, Deck Trim Side Service Hole, RH |
| 64735G | Cover, Deck Trim Side Service Hole, LH |
| 64750F | Clip(FOR DECK SIDE TRIM PANEL) |
| 64753A | Garnish, Deck Side, Rear, RH |
| 64754A | Garnish, Deck Side, Rear, LH |
| 64760C | Clip(FOR DECK SIDE TRIM PANEL) |
| 64766B | Cover, Quarter Trim Jack |
| 67771H | Retainer, Door Trim |
| 67910 | Plate Assy, Door Scuff, RH |
| 67917C | Plate, Rear Door Scuff, RH |
| 67918E | Plate, Rear Door Scuff, LH |
| 67920 | Plate Assy, Door Scuff, LH |
| 67921F | Retainer, Front Door Scuff Plate |
| 67923C | Clamp, Door Scuff Plate, NO.1 |
| 67924A | Clamp, Door Scuff Plate, NO.2 |
| 71397E | Stopper, Rear Seat |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
