Toyota Alphard/Vellfire
2023-06 → present · chassis AAHH4#,AAHP45,AGH40,TAHA40 · catalogue 713250 · General
Supported model
Data version 2024-10
Roof Headlining & Silencer Pad
27 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 55557E | Cushion, Roof Console Box |
| 58821E | Panel, Console, Upper Front |
| 58822E | Panel, Console, Upper Rear |
| 58932B | Garnish, Rear Console Box |
| 63304D | Trim Sub-assy, Roof Headlining |
| 63310K | Clip |
| 63317A | Retainer, Roof Headlining |
| 63365A | Plate, Roof Headlining Set |
| 63381 | Retainer, Headlining, Front |
| 63388A | Cover, Roof Headlining Holder |
| 63388G | Cover, Roof Headlining Holder, NO.2 |
| 63398 | Plate, Roof Headlining Support |
| 63412B | Retainer, Roof Console |
| 63605B | Box Sub-assy, Roof Console |
| 63650A | Box Assy, Roof Console |
| 63650D | Clip(FOR ROOF CONSOLE BOX) |
| 63651C | Box, Roof Console |
| 63652F | Cover, Roof Console Box, Rear |
| 63653B | Cover, Roof Console Box, Front |
| 63654B | Cover, Roof Console Box, Inner |
| 63660D | Lock Assy, Roof Console |
| 63665 | Spacer, Roof Headlining |
| 64364A | Clip |
| 65896J | Cap, Cover Top Set Bolt |
| 84662B | Panel, Cooler Control Switch |
| 85643C | Cushion, Stopper |
| 86255F | Case, Microphone |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
