Toyota Lexus LM350/LM300H
2020-01 → present · chassis AYH36,GGH31 · catalogue 714310 · General
Supported model
Data version 2020-02
Inside Trim Board
102 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 55633C | Support, Cup Holder, NO.1 |
| 55633D | Support, Cup Holder, NO.2 |
| 55973A | Duct, Side Defroster Nozzle, NO.3 |
| 55974A | Duct, Side Defroster Nozzle, NO.4 |
| 62111B | Clip(FOR COWL SIDE TRIM) |
| 62111C | Board, Cowl Side Trim, RH |
| 62112 | Board, Cowl Side Trim, LH |
| 62117B | Clip, NO.1(FOR COWL SIDE TRIM) |
| 62170A | Airbag Assy, Curtain Shield, RH |
| 62170B | Bolt, W/Washer |
| 62180A | Airbag Assy, Curtain Shield, LH |
| 62189A | Spacer, Curtain Shield Airbag Clip |
| 62211 | Garnish, Front Pillar, RH |
| 62211T | Clip(FOR FRONT PILLAR GARNISH) |
| 62212 | Garnish, Front Pillar, LH |
| 62225A | Garnish, Front Pillar, Lower RH |
| 62226 | Garnish, Front Pillar, Lower LH |
| 62311B | Weatherstrip, Front Door Opening Trim, RH |
| 62312B | Weatherstrip, Front Door Opening Trim, LH |
| 62401A | Clip (FOR CENTER PILLAR GARNISH PANEL, UPPER) |
| 62411 | Garnish, Center Pillar, RH |
| 62411F | Clip, Center Pillar Garnish, RH |
| 62412 | Garnish, Center Pillar, LH |
| 62412E | Clip, Center Pillar Garnish, LH |
| 62413A | Garnish, Center Pillar, Lower RH |
| 62413C | Clip (FOR CENTER LOWER GARNISH) |
| 62414A | Garnish, Center Pillar, Lower LH |
| 62430 | Garnish Assy, Roof Side Rail, RH |
| 62430A | Clip, Roof Side Rail Garnish |
| 62440 | Garnish Assy, Roof Side Rail, LH |
| 62450A | Garnish Assy, Roof Side Rail, Rear RH |
| 62460A | Garnish Assy, Roof Side Rail, Rear LH |
| 62470A | Garnish Assy, Roof Side, Inner RH |
| 62480A | Garnish Assy, Roof Side, Inner LH |
| 62487A | Cover, Roof Side Inner Garnish, RH |
| 62488A | Cover, Roof Side Inner Garnish, LH |
| 62531A | Spacer, Quarter Trim, RH |
| 62532A | Spacer, Quarter Trim, LH |
| 62571D | Garnish, Quarter Lock Pillar, RH |
| 62572D | Garnish, Quarter Lock Pillar, LH |
| 62595B | Bezel, Quarter Trim Pocket, RH |
| 62595H | Plate, Side Trim Base, NO.5 |
| 62596B | Bezel, Quarter Trim Pocket, LH |
| 62596E | Plate, Side Trim Base, NO.6 |
| 62597D | Clip |
| 62627B | Cover, Quarter Trim |
| 62628B | Cover, Quarter Trim, LH |
| 62630P | Panel Assy, Quarter Trim, Rear RH |
| 62640P | Panel Assy, Quarter Trim, Rear LH |
| 62681A | Ornament, Quarter Trim, RH |
| 62682 | Ornament, Quarter Trim, LH |
| 64715C | Cover, Deck Side Trim, LH |
| 64718D | Cover, Deck Trim Service Hole |
| 64721J | Cover, Luggage Compartment Trim, Inner RH |
| 64722C | Cover, Luggage Compartment Trim, Inner LH |
| 64725F | Hook, Luggage Compartment Trim, NO.1 |
| 64726F | Hook, Luggage Compartment Trim, NO.2 |
| 64753A | Garnish, Deck Side, Rear, RH |
| 64754A | Garnish, Deck Side, Rear, LH |
| 64763B | Silencer, Deck Side Trim, RH |
| 64764A | Silencer, Deck Side Trim, LH |
| 64766 | Cover Sub-assy, Quarter Trim Jack |
| 65988A | Hook, Sunshade |
| 65991E | Curtain, Rear Window, RH |
| 65992C | Curtain, Rear Window, LH |
| 66310H | Hook Assy, Rope |
| 66991 | Holder, Quarter Trim Cup, RH |
| 66991A | Holder, Quarter Trim Cup, LH |
| 66991B | Holder, Cup, NO.1 |
| 66992 | Holder, Cup, NO.2 |
| 67679A | Bezel, Sunshade, RH |
| 67699B | Bezel, Sunshade, LH |
| 67771H | Retainer, Door Trim |
| 67865L | Weatherstrip, Front Door, NO.3 RH |
| 67866J | Weatherstrip, Front Door, NO.3 LH |
| 67871H | Weatherstrip, Slide Door, NO.1 RH |
| 67872C | Weatherstrip, Slide Door, NO.1 LH |
| 67895F | Weatherstrip, Slide Door, NO.3 RH |
| 67896B | Weatherstrip, Slide Door, NO.3 LH |
| 67910 | Plate Assy, Door Scuff, RH |
| 67917C | Plate, Rear Door Scuff, RH |
| 67917D | Clip, Rear Door Scuff Plate |
| 67918E | Plate, Rear Door Scuff, LH |
| 67920 | Plate Assy, Door Scuff, LH |
| 67921E | Retainer, Rear Door Scuff Plate |
| 67921F | Retainer, Front Door Scuff Plate |
| 67923C | Clamp, Door Scuff Plate, NO.1 |
| 67924A | Clamp, Door Scuff Plate, NO.2 |
| 72083C | Pad Sub-assy, Rear Seat Armrest, RH |
| 72084C | Pad Sub-assy, Rear Seat Armrest, LH |
| 74253 | Base, Quarter Armrest, RH |
| 74254 | Base, Quarter Armrest, LH |
| 74261B | Cover, Quarter Armrest, RH |
| 74262B | Cover, Quarter Armrest, LH |
| 74271C | Panel, Quarter Armrest Base, RH |
| 74272C | Panel, Quarter Armrest Base, LH |
| 74287 | Reinforcement, Quarter Armrest, RH |
| 74288 | Reinforcement, Quarter Armrest, LH |
| 74293G | Bracket, Quarter Armrest, NO.1 RH |
| 74294B | Bracket, Quarter Armrest, NO.1 LH |
| 74295A | Bracket, Quarter Armrest, NO.2 RH |
| 74296A | Bracket, Quarter Armrest, NO.2 LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
