Toyota Lexus LM350/LM300H

2020-01 → present · chassis AYH36,GGH31 · catalogue 714310 · General

Supported model Data version 2020-02
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Seat Rail

15 part groups · 2 illustrations

Illustrations

Figure 71C262A 71C262A 2020-01 → — Figure 71C263A 71C263A 2020-02 → —

Part groups

PNCDescription
57066D Member Sub-assy, Rear Floor Cross, NO.1
57067B Member Sub-assy, Rear Floor Cross, NO.2
72129J Protector, Seat Track Lower Rail, RH Outer NO.1
72129P Protector, Seat Track Lower Rail, LH Inner NO.1
72129R Protector, Seat Track Lower Rail, LH Outer NO.1
72129T Protector, Seat Track Lower Rail, RH Inner NO.1
72160H Track Assy, Rear Seat, Outer RH
72160J Track Assy, Rear RH Seat, Inner NO.1
72160K Track Assy, Rear LH Seat, Inner NO.1
72170A Track Assy, Rear Seat, Outer LH
72180F Track Assy, Rear Seat, Inner RH
72190E Track Assy, Rear Seat, Inner LH
72275D Stopper, Rear Seat Track Slide, RH NO.1
72615K Cover, Rear Seat Lock Striker, RH
72615L Cover, Rear Seat Lock Striker, LH
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
