Toyota Lexus LM350/LM300H
2020-01 → present · chassis AYH36,GGH31 · catalogue 714310 · General
Supported model
Data version 2020-02
Caution Plate
24 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 11293D | Label, Engine Caution |
| 11298B | Label, Emission Control Information |
| 16793B | Label, Cooling Fan Information |
| 41992 | Label, Differential Notice |
| 42661 | Label, Tire Pressure Information |
| 55786G | Plate, Cowl Top Ventilator Louver |
| 74511F | Label, Name (IDENTIFICATION LASER LABEL) |
| 74528G | Label, Power Slide Door Caution |
| 74528H | Label, Power Slide Door Caution |
| 74528J | Label, Power Back Door Caution |
| 74529 | Plate, Child Proof OR Child Protector Lock Caution |
| 74535B | Plate, Tail Gate Caution |
| 74541B | Plate, Compact Spare Tire Caution |
| 74541E | Plate, Compact Spare Tire Caution |
| 74541H | Plate, Body Caution |
| 74543L | Label, Rear Seat Caution, NO.1 |
| 74543M | Label, Rear Seat Caution, NO.2 |
| 74543R | Label, Rear Seat Caution |
| 74548 | Plate, Body Caution |
| 74559B | Label, Fuel Information |
| 74596A | Label, Side Airbag Caution |
| 88723H | Label, Cooler Service Caution |
| 89356A | Label, Clearance Warning Information |
| G9275 | Label, Battery Caution, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
