Toyota Toyoace
1979-03 → 1985-07 · chassis RY20,3#,LY20,3#,JY30 · catalogue 731230 · General
Discontinued model
Data version 1986-05
Wiring & Clamp
15 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 82001 | Cable, Bond, NO.1 |
| 82031 | Wire Sub-assy, Ignition Coil |
| 82121 | Wire, Engine |
| 82131 | Wire, Cowl |
| 82161 | Wire, Floor |
| 82210C | Fusible Link |
| 82210D | Fusible Link |
| 82210E | Fusible Link |
| 82213A | Bracket, Harness Connector |
| 82219 | Wire, Thermo Sensor |
| 82241C | Wire, Relay |
| 82259 | Wire, Distributor |
| 82350 | Wiring Assy, Courtesy Lamp Switch (FOR FR OR RR DOOR) |
| 82512 | Harness Assy, Room Lamp Sub Wire |
| 82817 | Protector, Wiring Harness, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
