Toyota Dyna
2021-08 → present · chassis GDY231,LY230 · catalogue 731280 · General
Supported model
Data version 2022-02
Instrument Panel & Glove Compartment
46 part groups · 8 illustrations
Part groups
| PNC | Description |
|---|---|
| 45288C | Plate, Steering Column Cover |
| 55045 | Panel Sub-assy, Instrument Panel Finish, Lower |
| 55301 | Panel Sub-assy, Instrument |
| 55306A | Brace Sub-assy, Instrument Panel, NO.1 |
| 55312 | Panel, Instrument, Lower |
| 55321A | Cover,Instrument Panel Hole |
| 55326A | Stay, Instrument Panel, NO.1 |
| 55326C | Stay, Instrument Panel, NO.2 |
| 55330B | Reinforcement Assy, Instrument Panel |
| 55345A | Clip, Instrument Panel, NO.1 |
| 55346A | Clip, Instrument Panel, NO.2 |
| 55374B | Bracket, Instrument Panel |
| 55394B | Bolt, Instrument Panel |
| 55405B | Panel Sub-assy, Instrument Cluster Finish, Center |
| 55408F | Panel Sub-assy, Instrument Panel Speaker, NO.1 |
| 55409F | Panel Sub-assy, Instrument Panel Speaker, NO.2 |
| 55411G | Panel, Instrument Cluster Finish, NO.1 |
| 55432B | Panel, Instrument Panel Finish, Lower |
| 55433B | Panel, Instrument Panel Finish, Lower NO.2 |
| 55440C | Box Assy, Instrument Panel |
| 55442H | Door, Instrument Panel |
| 55448B | Cover, Oil Reservoir Tank, RH |
| 55449B | Cover, Oil Reservoir Tank, LH |
| 55451C | Box, Instrument Panel, NO.1 |
| 55452A | Box, Instrument Panel, NO.2 |
| 55458B | Cover, Instrument, Lwr |
| 55460C | Lock Assy, Instrument Panel Box |
| 55479C | Clip(FOR INSTRUMENT LOWER COVER) |
| 55501A | Door Sub-assy, Glove Compartment |
| 55521C | Cover, Stereo Opening |
| 55521F | Cover, Stereo Opening, NO.2 |
| 55537A | Cover, Throttle Knob Hole |
| 55539 | Cover, Spare Switch Hole |
| 55545 | Cover, Fuse Box Opening |
| 55547 | Cover, Remote Control Mirror Hole |
| 55548A | Cover, Instrument Panel Hole |
| 55549B | Cover, Instrument Panel Hole, NO.2 |
| 55556A | Arm, Glove Compartment Door Check, RH |
| 55557A | Cushion, Glove Compartment Door Check |
| 55573B | Arm, Glove Compartment Door Check, LH |
| 55631A | Stopper, Instrument Panel Under Tray, NO.1 |
| 55650 | Register Assy, Instrument Panel, NO.1 |
| 55650C | Register Assy, Instrument Panel, NO.1 |
| 58819B | Cover, Front Heater |
| 61184B | Bracket, Instrument Panel Side, NO.2 LH |
| 73970A | Airbag Assy, Instrument Panel Passenger |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
