Toyota Dyna
1999-07 → 2002-12 · chassis XZU30#,320,330,34# · catalogue 751270 · General
Discontinued model
Data version 2003-08
Mirror
14 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 87096 | Stay Sub-assy, Outer Rear View Mirror, Lower LH |
| 87810 | Mirror Assy, Inner Rear View |
| 87901B | Mirror Sub-assy, Outer Rear View, RH |
| 87906B | Mirror Sub-assy, Outer Rear View, LH |
| 87907 | Mirror Sub-assy, Outer Under View |
| 87910 | Mirror Assy, Outer Rear View, RH |
| 87914B | Cover, Outer Mirror Knob, RH |
| 87914C | Cover, Outer Mirror Knob, LH |
| 87915 | Cover, Outer Mirror, RH |
| 87916 | Bezel, Outer Mirror |
| 87919A | Bracket, Outer Mirror |
| 87940 | Mirror Assy, Outer Rear View, LH |
| 87945 | Cover, Outer Mirror, LH |
| 87965 | Grommet, Outer Mirror |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
