Toyota Dyna
2002-09 → present · chassis BU3##,WU3##,XZU3## · catalogue 751280 · General
Discontinued model
Data version 2022-03
Mechanical Governor
130 part groups · 10 illustrations
Part groups
| PNC | Description |
|---|---|
| 21038A | Compensator Sub-assy, Idle |
| 22013 | Housing Sub-assy, Fullroad Stopper |
| 22013B | Ring, O(FOR FULLROAD STOPPER HOUSING) |
| 22013C | Housing, Fullroad Stopper, NO.2 |
| 22013D | Ring, O(FOR FULLROAD STOPPER HOUSING, NO.2) |
| 22015 | Lever Sub-assy, Floating |
| 22135 | Nut, Adjusting Tappet |
| 22306C | Housing Sub-assy, Governor |
| 22313 | Lever, Injection Pump Stop |
| 22317A | Spring, Idling |
| 22329B | Bolt, Diaphragm Connecting, NO.3 |
| 22338B | Pin, Lever Conecting |
| 22365A | Ring, E(FOR INJECTION PUMP LEVER) |
| 22401 | Housing Sub-assy, Mechanical Governor |
| 22404 | Flyweight Sub-assy |
| 22408 | Arm, Stopper |
| 22408A | Arm Sub-assy(FOR CONTROL LACK) |
| 22408B | Spring, Return(FOR ARM) |
| 22408C | Nut, Arm |
| 22408F | Arm Sub-assy, Governor |
| 22408G | Arm Sub-assy, Governor |
| 22410 | Governor Assy, Injection Pump Mechanical |
| 22412 | Spring, Mechanical Governor |
| 22416 | Washer, Governor Lock |
| 22418 | Bushing, Governor Bearing |
| 22419 | Lever, Stop |
| 22419B | Washer, Plate(FOR STOPPER LEVER) |
| 22419C | Spring, Return(FOR STOPPER LEVER) |
| 22419D | Ring, O(FOR STOPPER LEVER) |
| 22420 | Housing Sub-assy, Mechanical Governor |
| 22420B | Bush, Mechanical Governor Housing |
| 22421 | Spring, Idling |
| 22421C | Washer, Idling Spring |
| 22422A | Shackle, Governor |
| 22424A | Arm, Spring |
| 22424B | Spring, Return(FOR SPRING ARM) |
| 22429 | Ring, E |
| 22432B | Shim |
| 22433A | Screw, Adapter(FOR SLIDING BLOCK) |
| 22433B | Spring(FOR ADAPTER SCREW) |
| 22433C | Bush(FOR ADAPTER SCREW) |
| 22433E | Adapter, Governor |
| 22433F | Adapter, Governor |
| 22434 | Shackle |
| 22437D | Nut, Governor Cap |
| 22440 | Flyweight Sub-assy |
| 22440B | Flyweight Sub-assy |
| 22440C | Spring Sub-assy, Return |
| 22440D | Spring Sub-assy, Return |
| 22440E | Spring Sub-assy, Return |
| 22440F | Spring Sub-assy, Return |
| 22442A | Gasket, Governor |
| 22453 | Spring, Adapter |
| 22454A | Collar, Governor Adaptor |
| 22456 | Screw, Stop |
| 22457 | Shaft |
| 22458 | Screw, Stop |
| 22458A | Plate, Governor Cover |
| 22459 | Nut |
| 22460 | Lever Sub-assy, Support |
| 22460D | Washer, Lock(FOR STEERING LEVER) |
| 22460E | Arm Assy, Guide |
| 22461 | Plug, Screw |
| 22463B | Tube, Rubber |
| 22464A | Block, Sliding |
| 22465 | Lever Sub-assy, Adjusting |
| 22465A | Key, Woodruff(FOR ADJUSTING LEVER) |
| 22465B | Seal, Oil(FOR ADJUSTING LEVER) |
| 22467 | Nut, Round |
| 22468 | Cover, Plate |
| 22468A | O, Ring |
| 22470A | Lever Assy, Adjusting |
| 22471 | Lever Sub-assy, Guide |
| 22471A | Shaft, Lever Supporting |
| 22478A | Shaft, Lever Supporting |
| 22480 | Cover Sub-assy, Governor |
| 22480A | Bolt |
| 22480E | Gasket, Governor Cover |
| 22481 | Gasket |
| 22481A | Seat, Spring, Inner |
| 22481B | Seat, Governor Spring, Inner A |
| 22482A | Seat, Governor Spring, Inner B |
| 22490A | Lever Assy, Control |
| 22491 | Lever Kit, Control |
| 22491A | Lever Kit, Control |
| 22551 | Seat, Spring(FOR FLYWEIGHT) |
| 22552A | Spring, Return(FOR CAM PLATE) |
| 22552C | Washer(FOR CAM PLATE BUSH) |
| 22552D | Plate, Cam |
| 22555 | Bracket, Stopper |
| 22557 | Cam, Full Stop |
| 22557A | Pin, Connecting(FOR FULL STOP CAM) |
| 22557B | Washer, Plate(FOR CONNECTING PIN) |
| 22557C | Ring, E(FOR CONNECTING PIN) |
| 22558 | Shaft, Sliding Block |
| 22558A | Spring(FOR SLIDING BLOCK SHAFT) |
| 22572A | Bush, Suction Control Valve |
| 22579 | Actuator, Fuel Cut |
| 22579B | Actuator, Idle UP Diaphragm |
| 22699A | Bracket, Adjusting |
| 22702 | Lever Assy, Floating |
| 22702A | Spring, Floating Arm |
| 22702B | Washer, Plate(FOR FLOATING LEVER) |
| 22702C | Arm, Floating |
| 22702E | Lever Sub-assy, Control |
| 22702F | Spring, Return(FOR CONTROL LEVER) |
| 22707 | Lever, Stop |
| 22707A | Collar, Stop Lever |
| 22711A | Housing, Governor |
| 22720 | Flyweight Assy |
| 22723 | Damper, Flyweight Holder |
| 22725 | Spring, Idling |
| 22726A | Spring, Speed Control |
| 22727 | Spring, Speed Control, B |
| 22728A | Guide, Spring |
| 22729 | Nut, Adjusting(FOR FLYWEIGHT) |
| 22730 | Bushing Assy, Camshaft |
| 22736 | Bolt, Bellcrank |
| 22738 | Bushing, Guide(FOR FLYWEIGHT) |
| 22757 | Spring, Speed Control, A |
| 22761 | Slider(FOR SPEED CONTROL) |
| 22761A | Shaft, Sliding Weight |
| 22771 | Lever, Floating |
| 22776B | Nut, Cap(FOR SCREW STOPPER) |
| 22776C | Screw, Stopper |
| 22795 | Plug, Screw |
| 22795A | Washer, Screw Plug |
| 23205 | Bracket Sub-assy |
| 23503A | Lever Sub-assy |
| 23503B | Lever Sub-assy |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
