Toyota Dyna
2002-09 → present · chassis BU3##,WU3##,XZU3## · catalogue 751280 · General
Discontinued model
Data version 2022-03
Rear Body Floor & Fender
55 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 60531 | Frame Sub-assy, Floor Side, RH |
| 60532 | Frame Sub-assy, Floor Side, LH |
| 65026 | Bracket Sub-assy, Gate Rubber Bumper, RH |
| 65027 | Bracket Sub-assy, Gate Rubber Bumper, LH |
| 65100 | Floor Assy, Rear Body |
| 65110 | Sill Assy, Main, RH |
| 65120 | Sill Assy, Main, LH |
| 65125A | Shim, Main Sill, Lower NO.1 |
| 65137 | Cover, Main Sill End |
| 65150 | Sill Assy, Cross, NO.1 |
| 65160 | Sill Assy, Cross, NO.2 |
| 65160A | Sill Assy, Cross, NO.2 |
| 65160B | Sill Assy, Cross, NO.2 |
| 65170 | Sill Assy, Cross, NO.2 |
| 65180 | Sill Assy, Cross, NO.4 |
| 65190 | Sill Assy, Cross, NO.5 |
| 65220 | Sill Assy, Cross, NO.4 |
| 65240 | Crossmember, Rear Body Floor, Tail |
| 65240C | Sill Assy, Cross, NO.9 |
| 65250 | Sill Assy, Cross, NO.2 |
| 65263 | Reinforcement, Floor Side Frame |
| 65287A | Bracket, Gate Rubber Bumper, RH |
| 65288B | Bracket, Gate Rubber Bumper, LH |
| 65307A | Frame Sub-assy, Floor, Rear |
| 65311 | Panel, Floor, Center |
| 65317 | Panel, Floor Side, RH |
| 65318 | Panel, Floor Side, LH |
| 65320 | Plate, Rear Floor End |
| 65322 | Nail |
| 65349 | Fender, Floor Side |
| 65413A | Bracket, Guard Frame, RH |
| 65415D | Bracket, Guard Frame, LH |
| 66010A | Fender Assy, Rear NO.2 RH |
| 66020A | Fender Assy, Rear NO.2 LH |
| 66115D | Retainer, Gate Hinge |
| 66135 | Gusset, Gate Hinge, RH |
| 66210A | Fender Assy, Rear NO.1 RH |
| 66220A | Fender Assy, Rear NO.1 LH |
| 66225A | Support, Baffle Rubber |
| 66225B | Support, Buffle Rubber |
| 66241B | Baffle, Rubber |
| 66241C | Buffle, Rubber |
| 66259A | Cover, Rear Body Floor, Rear |
| 66312D | Hook, Rope, NO.2 |
| 66312E | Hook, Rope, NO.2 |
| 66312F | Hook, Rope, NO.2 |
| 66312G | Hook, Rope, NO.2 |
| 66313 | Support, Rear Fender |
| 66315A | Hook, Rope |
| 66321E | Bumper, Gate Rubber |
| 66321G | Bumper, Gate Rubber |
| 75139A | Bracket, Reflex Reflector, RH |
| 75149 | Bracket, Reflex Reflector, LH |
| 76625B | Mudguard, Rear Body, RH |
| 76626B | Mudguard, Rear Body, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
