Toyota Dyna
2011-07 → present · chassis WU600,650,XZU600,650 · catalogue 751290 · General
Supported model
Data version 2020-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 11176 — Seat, Injection Nozzle | ||||
| S1117-61200 |
Seat, Injection Nozzle
2016-05 → 2020-05
ended
|
N04C XZU600,650 GCC | — | |
| SZ910-11017 |
Seat, Injection Nozzle
2011-07 → 2020-05
ended
|
W04D WU600,650 | — | |
| S1117-61200 |
Seat, Injection Nozzle
2019-11 → —
|
N04C XZU600 GEN | — | |
| 11176C — Gasket, NO.2(FOR INJECTION NOZZLE SEAT) | ||||
| SZ910-15133 |
Gasket, NO.2(FOR INJECTION NOZZLE SEAT)
2016-05 → 2020-05
ended
|
N04C XZU600,650 GCC | — | |
| SZ910-15133 |
Gasket, NO.2(FOR INJECTION NOZZLE SEAT)
2019-11 → —
|
N04C XZU600 GEN | — | |
| 11177 — Gasket, Injection Nozzle Seat | ||||
| 23682-E0050 |
Gasket, Injection Nozzle Seat
2016-05 → 2020-05
ended
|
N04C XZU600,650 GCC | — | |
| S2366-11140 |
Gasket, Injection Nozzle Seat
2011-07 → 2020-05
ended
|
W04D WU600,650 | — | |
| 23682-E0050 |
Gasket, Injection Nozzle Seat
2019-11 → —
|
N04C XZU600 GEN | — | |
| 23627A — Screw, Follow(FOR NOZZLE) | ||||
| 21811-E0050 |
Screw, Follow(FOR NOZZLE)
2012-10 → 2020-05
ended
|
W04D WU600 DCRTJ;W04D WU600 +3 | — | |
| 21811-E0050 |
Screw, Follow(FOR NOZZLE)
2016-05 → 2020-05
ended
|
N04C XZU600,650 GCC | — | |
| S2283-51320 |
Screw, Follow(FOR NOZZLE)
2011-07 → 2020-05
ended
|
W04D WU600 ST CBU;W04D +7 | — | |
| S2283-51570 |
Screw, Follow(FOR NOZZLE)
2011-07 → 2012-10
ended
|
W04D WU600 DCRTJ;W04D WU600 +3 | — | |
| 21811-E0050 |
Screw, Follow(FOR NOZZLE)
2019-11 → —
|
N04C XZU600 GEN | — | |
| 23627C — Washer(FOR NOZZLE) | ||||
| SZ209-08024 |
Washer(FOR NOZZLE)
2016-05 → 2020-05
ended
|
N04C XZU600,650 GCC | — | |
| SZ209-08024 |
Washer(FOR NOZZLE)
2019-11 → —
|
N04C XZU600 GEN | — | |
| 23670 — Injector Assy | ||||
| 23670-E9271 |
Injector Assy
2016-05 → 2016-08
ended
|
N04C XZU600,650 | — | |
| 23670-E9272 |
Injector Assy
2016-08 → 2017-02
ended
|
N04C XZU600,650 | — | |
| 23670-E9273 |
Injector Assy
2017-02 → 2020-05
ended
|
N04C XZU600,650 GCC | — | |
| 23670-E9470 |
Injector Assy
2019-11 → —
|
N04C XZU600 GEN | — | |
| 23670A — Ring, O(FOR INJECTOR ASSY) | ||||
| 15518-E0010 |
Ring, O(FOR INJECTOR ASSY)
2016-05 → 2017-02
ended
|
N04C XZU600,650 | — | |
| 15518-E0011 |
Ring, O(FOR INJECTOR ASSY)
2017-02 → 2020-05
ended
|
N04C XZU600,650 GCC | — | |
| 15518-E0011 |
Ring, O(FOR INJECTOR ASSY)
2019-11 → —
|
N04C XZU600 GEN | — | |
| 23695 — Clamp, Nozzle Holder, NO.1 | ||||
| S1119-51140 |
Clamp, Nozzle Holder, NO.1
2016-05 → 2020-05
ended
|
N04C XZU600,650 GCC | — | |
| S1119-51140 |
Clamp, Nozzle Holder, NO.1
2019-11 → —
|
N04C XZU600 GEN | — | |
| 23760 — Pipe Assy, Nozzle Leakage | ||||
| 23708-78031 |
Pipe Assy, Nozzle Leakage
2019-05 → 2020-05
ended
|
N04C XZU600,650 GCC | — | |
| 23708-E0090 |
Pipe Assy, Nozzle Leakage
2011-07 → 2020-05
ended
|
W04D WU600 ST CBU;W04D +7 | — | |
| 23761-E0020 |
Pipe Assy, Nozzle Leakage
2011-07 → 2020-05
ended
|
W04D WU600 DCRTJ;W04D WU600 +3 | — | |
| S2308-12630 |
Pipe Assy, Nozzle Leakage
2016-05 → 2019-05
ended
|
N04C XZU600,650 | — | |
| 23708-78031 |
Pipe Assy, Nozzle Leakage
2019-11 → —
|
N04C XZU600 GEN | — | |
| 23760A — Gasket | ||||
| SZ209-08024 |
Gasket
2016-05 → 2020-05
ended
|
N04C XZU600,650 GCC | — | |
| SZ209-08024 |
Gasket
2019-11 → —
|
N04C XZU600 GEN | — | |
| 23760B — Bolt, Union(FOR NOZZLE LEAKAGE PIPE) | ||||
| 21811-E0060 |
Bolt, Union(FOR NOZZLE LEAKAGE PIPE)
2016-05 → 2020-05
ended
|
N04C XZU600,650 GCC | — | |
| 21811-E0060 |
Bolt, Union(FOR NOZZLE LEAKAGE PIPE)
2019-11 → —
|
N04C XZU600 GEN | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
