Toyota Dyna
2011-07 → present · chassis WU600,650,XZU600,650 · catalogue 751290 · General
Supported model
Data version 2020-01
Tool Box & License Plate Bracket
13 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 47379 | Spacer, Brake Tube, NO.1 |
| 47379A | Spacer, Brake Tube, NO.2 |
| 58794B | Support, Jack Handle |
| 58797B | Band, Jack Clamp |
| 66407 | Stay Sub-assy, License Plate Bracket |
| 66490 | Hanger Assy, License Plate Bracket |
| 75102 | Bracket Sub-assy, Rear License Plate |
| 75135 | Bracket, Combination Rear Lamp, RH |
| 75136 | Bracket, Combination Rear Lamp, LH |
| 75201 | Box Sub-assy, Tool W/Stay |
| 75204B | Stay Sub-assy, Tool Box |
| 75209A | Base Sub Assy, Jack Holder |
| 75247B | Support, Tool Box |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
