Toyota Dyna 200
1988-08 → 1997-03 · chassis BU6#,70,8#,9# · catalogue 751350 · General
Discontinued model
Data version 1997-10
Switch & Relay & Computer
82 part groups · 7 illustrations
Part groups
| PNC | Description |
|---|---|
| 27679 | Bracket, Exhaust Brake(FOR SOLENOID) |
| 27690 | Solenoid Assy, W/Bracket(FOR EXHAUST BRAKE) |
| 28300 | Relay Assy, Starter |
| 28371A | Relay, Bulb Check |
| 28490A | Relay Assy, Exhaust Retarder |
| 28521 | Timer, Preheating |
| 28610 | Relay Assy, Intake Heater OR Glow Plug |
| 28611 | Cover, Glow Plug Relay |
| 58484A | Packing, Battery Cable Switch |
| 74468A | Bracket, Relay Block |
| 74468C | Bracket, Relay Block, NO.3 |
| 81420 | Socket Sub-assy, Inspection Lamp, NO.2 |
| 81980 | Flasher Assy, Turn Signal |
| 82600F | Fuse, Fuse Block |
| 82611 | Cover, Fuse Block |
| 82616 | Puller, Fuse |
| 82650 | Breaker Assy, Wiring Circuit, NO.1 |
| 83320 | Gage Assy, Fuel Sender |
| 83361 | Gasket, Fuel Sender Gage |
| 83381A | Switch, Pressure |
| 83389A | Bracket, Pressure Switch |
| 83390 | Switch Assy, Vacuum Warning |
| 83420 | Gage Assy, Water Temperature Sender |
| 83530 | Switch Assy, Oil Pressure (FOR ENGINE) |
| 83970B | Buzzer Assy, Reverse Warning |
| 84110 | Switch Assy, Light Control, NO.1 |
| 84113A | Bracket, Switch, NO.1 |
| 84118 | Knob, Light Control Rheostat |
| 84119 | Rheostat, Light Control |
| 84140 | Switch Assy, Headlamp Dimmer |
| 84162 | Switch, Front Fog Lamp |
| 84162B | Bulb, Fog Lamp Switch |
| 84210 | Switch Assy, Back-up Lamp |
| 84220C | Switch Assy, Transmission Position Indicator |
| 84233 | Switch Assy, Courtesy Lamp (FOR FRONT DOOR) |
| 84235 | Switch Assy, Courtesy Lamp(FOR BACK DOOR) |
| 84310 | Switch Assy, Turn Signal |
| 84312 | Plate, Horn Contact |
| 84329 | Switch, Turn Signal |
| 84330 | Switch Assy, Hazard Warning Signal |
| 84330B | Bulb, Hazard Warning Signal Switch |
| 84340 | Switch Assy, Stop Lamp |
| 84430 | Switch Assy, Horn |
| 84450 | Switch Assy, Ignition OR Starter |
| 84461 | Switch, Level Warning |
| 84480 | Switch Assy, Main |
| 84510 | Switch Assy, Starter |
| 84540 | Switch Assy, Neutral Start |
| 84540C | Switch Assy, Neutral (FOR EXHAUST BRAKE) |
| 84550 | Switch Assy, Parking Brake |
| 84640C | Switch Assy, Exhaust Retarder |
| 84650 | Switch Assy, Windshield Wiper |
| 84730 | Switch Assy, Heater Blower |
| 84730B | Bulb, Heater Blower Switch |
| 84731 | Knob, Heater Blower Switch |
| 84734B | Plate, Main Switch Caution |
| 84763 | Plate, Switch |
| 84810 | Switch Assy, Power Window Regulator |
| 84820 | Master Switch Assy, Power Window Regulator |
| 85500 | Lighter Assy, Cigarette |
| 85909C | Bracket Sub-assy, Relay, NO.1 |
| 85909D | Bracket Sub-assy, Relay, NO.2 |
| 85909E | Bracket Sub-assy, Relay, NO.3 |
| 85910C | Relay Assy (FOR HEATER BLOWER MOTOR) |
| 85910P | Relay, Turbo Indicator |
| 85916 | Relay, Light Control |
| 85925A | Relay, Red Indicator |
| 85926 | Relay, Headlamp Dimmer |
| 85930 | Relay Assy, Power Window |
| 85959A | Holder, Relay |
| 85991 | Relay, Seat Belt Warning |
| 85999A | Bracket, Relay, NO.2 |
| 86640 | Chime Assy |
| 86650 | Buzzer Assy, Vacuum Indicator |
| 86650B | Buzzer Assy, Reverse Warning |
| 89422A | Sensor, Water Temperature |
| 89428 | Switch, Temperature Detect, NO.2 |
| 89429 | Sensor, Oil Temperature |
| 89491 | Sensor, Engine Oil Level |
| 89530C | Computer Assy, Transmission Control |
| 89590 | Computer Assy, Condition Indicator |
| 89593 | Sensor, Air Cleaner Warning |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
