Toyota Dyna

1984-09 → 1987-08 · chassis RU75,85,YU6#,7#,8#,WU9# · catalogue 752230 · General

Discontinued model Data version 1988-01
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Mirror

9 part groups · 2 illustrations

Illustrations

Figure MEG676 MEG676 1984-09 → — Figure MEG677 MEG677 1984-09 → —

Part groups

PNCDescription
87810 Mirror Assy, Inner Rear View
87810B Bulb, Inner Rear View Mirror Lamp
87827 Absorber, Inner Rear View Mirror
87834 Cover, Inner Rear View Mirror Stay Holder
87901 Mirror Sub-assy, Outer Under View
87901B Mirror Sub-assy, Outer Rear View, RH
87902 Support, Rear View Outside Mirror, RH
87903 Support, Rear View Outside Mirror, LH
87906B Mirror Sub-assy, Outer Rear View, LH
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
