Toyota Land Cruiser Prado
2010-05 → 2020-06 · chassis GRJ150L-GKA*KC,GRJ152,TRJ150L-GK*EKC,TRJ152 · catalogue 780310 · General
Discontinued model
Data version 2020-06
Radiator Grille
7 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 53012 | Garnish Sub-assy, Radiator Grille, Center |
| 53111 | Grille, Radiator |
| 53115A | Bracket, Radiator Grille, RH |
| 53116A | Bracket, Radiator Grille, LH |
| 53145B | Clip, Radiator Grille Garnish |
| 53145E | Clip, Radiator Grille Garnish |
| 53395H | Seal, Hood TO Radiator Grille |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
