Toyota Land Cruiser
1987-08 → 1992-03 · chassis BJ60,HJ6#,FJ62 · catalogue 791330 · General
Discontinued model
Data version 1993-06
Heating & Air Conditioning - Control & Air Duct
24 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 55084C | Duct Sub-assy, Heater TO Register, NO.1 |
| 55085 | Duct Sub-assy, Heater TO Register, NO.2 |
| 55086 | Duct Sub-assy, Heater TO Register, NO.3 |
| 55087 | Duct Sub-assy, Heater TO Register, NO.4 |
| 55088 | Duct Sub-assy, Heater TO Register, NO.5 |
| 55089 | Duct Sub-assy, Heater TO Register, NO.6 |
| 55843A | Duct, Heater TO Register, NO.1 |
| 55906A | Cable Sub-assy, Defroster Damper Control |
| 55907A | Cable Sub-assy, Water Valve Control |
| 55908A | Cable Sub-assy, Air Inlet Damper Control |
| 55909A | Cable Sub-assy, Airmix Damper Control |
| 55910 | Control Assy, Heater OR Boost Ventilator |
| 55937 | Knob, Heater Control Lever |
| 55937A | Knob, Cooler Control Lever |
| 87211 | Duct, Air, NO.1 |
| 87211B | Duct, Air, NO.3 |
| 87211C | Duct, Air, NO.4 |
| 87284 | Resistor Sub-assy, Variable |
| 88565A | Adapter, Air Duct, NO.1 |
| 88566A | Duct, Cooler Air, NO.1 |
| 88566B | Duct, Cooler Air, NO.2 |
| 88566C | Duct, Cooler Air, NO.3 |
| 88570E | Grille Assy, Air Outlet |
| 88604F | Panel Sub-assy, Cooler Control |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
