Toyota Land Cruiser
1990-01 → 2006-12 · chassis FJ80,HDJ80,HZJ80,FZJ80 · catalogue 791340 · General
Discontinued model
Data version 2007-10
Vacuum Piping
28 part groups · 16 illustrations
Illustrations
Part groups
| PNC | Description |
|---|---|
| 17303B | Pipe Sub-assy, Air, NO.1 |
| 17303F | Hose, NO.2(FOR AIR PIPE) |
| 17340 | Hose Assy, Vacuum Switching Valve |
| 17630 | Valve Assy, Air Control |
| 17650 | Valve Assy, Vacuum Switching |
| 17650E | Valve, Vacuum Switching |
| 17650G | Valve, Duty Vacuum Switching |
| 17691 | Bracket, Vacuum Control Valve, NO.1 |
| 17810A | Filter Assy, Air |
| 23262 | Valve, Bimetal Vacuum Switching, NO.1 |
| 23265 | Filter, Gas, NO.1 |
| 23275 | Valve, Vacuum Control, NO.1 |
| 23281 | Valve, Vacuum Transmitting, NO.1 |
| 23281A | Valve, Vacuum Transmitting, NO.2 |
| 23285A | Valve, Check, NO.1 |
| 25701 | Valve Set, Emission Control |
| 25702 | Valve Set, Emission Control, NO.2 |
| 25702A | Clip(FOR VALVE SET, EMISSION CONTROL, NO.2) |
| 25706 | Pipe Sub-assy, Vacuum Transmitting, NO.1 |
| 25709 | Valve Sub-assy, High Altitude Compensator |
| 25712 | Wire, Emission Control Valve |
| 25715 | Bracket, Emission Control Valve |
| 25792 | Bracket, Altitude Compensator Valve |
| 25795 | Element, Altitude Compensator Filter |
| 25810 | Valve Assy, Bimetal |
| 25820 | Valve Assy, Bimetal, NO.2 |
| 25860 | Valve Assy, Vacuum Switching, NO.1 |
| 25860A | Valve, Vacuum Switching, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
