Toyota Coaster
1993-01 → 2016-12 · chassis BB4#,5#,BZB40,50,HZB50,RZB40,50,TRB40,50,XZB40,5# · catalogue 811230 · General
Discontinued model
Data version 2016-12
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 11177 — Gasket, Injection Nozzle Seat | ||||
| 11177-56010 |
Gasket, Injection Nozzle Seat
1993-01 → 1999-07
ended
|
3B BB40 | — | |
| 11177-64010 |
Gasket, Injection Nozzle Seat
1993-01 → 1999-07
ended
|
1HZ# HZB50 | — | |
| 90430-17003 |
Gasket, Injection Nozzle Seat
1993-01 → 1999-07
ended
|
14B BB42 | — | |
| 11177-54020 |
Gasket, Injection Nozzle Seat
1999-10 → 2001-08
ended
|
1HZ HZB50 RHD SRF;1HZ +8 | — | |
| 11177-54020 |
Gasket, Injection Nozzle Seat
1999-10 → 2002-11
ended
|
1HZ HZB50 ARL | — | |
| 11177-54020 |
Gasket, Injection Nozzle Seat
1999-10 → 2004-08
ended
|
1HZ .SRF HZB50 WC +11 | — | |
| 11177-64010 |
Gasket, Injection Nozzle Seat
1999-07 → 1999-10
ended
|
1HZ HZB50 | — | |
| 90430-17003 |
Gasket, Injection Nozzle Seat
1999-07 → 2001-08
ended
|
14B BB42 22S;14B BB42 +6 | — | |
| 90430-17003 |
Gasket, Injection Nozzle Seat
1999-07 → 2004-08
ended
|
14B WOC BB42 WC +11 | — | |
| 11177-54020 |
Gasket, Injection Nozzle Seat
2004-08 → 2015-01
ended
|
1HZ HZB50 | — | |
| 23682-78030 |
Gasket, Injection Nozzle Seat
2006-08 → 2008-03
ended
|
N04C XZB50 STD GEN | — | |
| 23682-78030 |
Gasket, Injection Nozzle Seat
2006-08 → 2009-08
ended
|
N04C XZB50 WOC CBU | — | |
| 23682-78030 |
Gasket, Injection Nozzle Seat
2006-08 → 2011-04
ended
|
N04C XZB40,59;N04C XZB50 IV;N04C +3 | — | |
| 23682-E0050 |
Gasket, Injection Nozzle Seat
2011-04 → 2013-11
ended
|
N04C XZB50 IV | — | |
| 23682-E0050 |
Gasket, Injection Nozzle Seat
2011-04 → 2015-01
ended
|
N04C XZB40,5# ARL,GEN,TAIW | — | |
| 90430-17003 |
Gasket, Injection Nozzle Seat
2004-08 → 2011-08
ended
|
14B BB42 LHD HRF | — | |
| 90430-17003 |
Gasket, Injection Nozzle Seat
2004-08 → 2015-01
ended
|
14B BB42 RHD;14B BB42 +2 | — | |
| 11177-54020 |
Gasket, Injection Nozzle Seat
2015-01 → —
|
1HZ HZB50 | — | |
| 23682-E0050 |
Gasket, Injection Nozzle Seat
2015-01 → —
|
N04C XZB40,5# | — | |
| 90430-17003 |
Gasket, Injection Nozzle Seat
2015-01 → —
|
14B BB42 | — | |
| 23627A — Screw, Follow(FOR NOZZLE) | ||||
| 23625-58230 |
Screw, Follow(FOR NOZZLE)
1993-01 → 1999-07
ended
|
14B BB42 | — | |
| 23656-78030 |
Screw, Follow(FOR NOZZLE)
1996-05 → 1999-07
ended
|
15BFT BB43,5# | — | |
| 23625-58230 |
Screw, Follow(FOR NOZZLE)
1999-07 → 2001-08
ended
|
14B BB42 22S;14B BB42 +6 | — | |
| 23625-58230 |
Screw, Follow(FOR NOZZLE)
1999-07 → 2004-08
ended
|
14B WOC BB42 WC +11 | — | |
| 23656-78030 |
Screw, Follow(FOR NOZZLE)
1999-07 → 2001-05
ended
|
15BFT BB50 WOC 6F;15BFT +4 | — | |
| 23656-78030 |
Screw, Follow(FOR NOZZLE)
1999-07 → 2001-08
ended
|
15BFT BB50 WOC 5F;15BFT +6 | — | |
| 23656-78030 |
Screw, Follow(FOR NOZZLE)
1999-07 → 2002-11
ended
|
15BFT BB50 CHI | — | |
| 23656-78030 |
Screw, Follow(FOR NOZZLE)
1999-07 → 2004-08
ended
|
15BFTE BB5#;15BFT BB50 STD +3 | — | |
| 21811-E0050 |
Screw, Follow(FOR NOZZLE)
2012-10 → 2015-01
ended
|
N04C XZB40,5# ARL,GEN,TAIW | — | |
| 21811-E0050 |
Screw, Follow(FOR NOZZLE)
2012-10 → 2013-11
ended
|
N04C XZB50 IV | — | |
| 23625-58230 |
Screw, Follow(FOR NOZZLE)
2004-08 → 2015-01
ended
|
14B BB42 RHD;14B BB42 +2 | — | |
| 23625-58230 |
Screw, Follow(FOR NOZZLE)
2004-08 → 2011-08
ended
|
14B BB42 LHD HRF | — | |
| 23656-78030 |
Screw, Follow(FOR NOZZLE)
2004-08 → 2015-01
ended
|
15BFT BB50 | — | |
| 23656-78030 |
Screw, Follow(FOR NOZZLE)
2004-08 → 2006-08
ended
|
15BFTE BB5# | — | |
| 90034-01017 |
Screw, Follow(FOR NOZZLE)
2006-08 → 2009-08
ended
|
N04C XZB50 WOC CBU | — | |
| 90034-01017 |
Screw, Follow(FOR NOZZLE)
2006-08 → 2012-10
ended
|
N04C XZB40,59;N04C XZB50 IV;N04C +3 | — | |
| 90034-01017 |
Screw, Follow(FOR NOZZLE)
2006-08 → 2008-03
ended
|
N04C XZB50 STD GEN | — | |
| 21811-E0050 |
Screw, Follow(FOR NOZZLE)
2015-01 → —
|
N04C XZB40,5# | — | |
| 23625-58230 |
Screw, Follow(FOR NOZZLE)
2015-01 → —
|
14B BB42 | — | |
| 23627C — Washer(FOR NOZZLE) | ||||
| 90032-09030 |
Washer(FOR NOZZLE)
2006-08 → 2007-06
ended
|
N04C XZB5# | — | |
| 90032-09032 |
Washer(FOR NOZZLE)
2007-06 → 2008-03
ended
|
N04C XZB50 STD GEN | — | |
| 90032-09032 |
Washer(FOR NOZZLE)
2007-06 → 2009-08
ended
|
N04C XZB50 WOC CBU | — | |
| 90032-09032 |
Washer(FOR NOZZLE)
2007-06 → 2013-11
ended
|
N04C XZB50 IV | — | |
| 90032-09032 |
Washer(FOR NOZZLE)
2007-06 → 2015-01
ended
|
N04C XZB40,59;N04C XZB50 (20S,21S) +1 | — | |
| SZ209-08024 |
Washer(FOR NOZZLE)
2015-01 → —
|
N04C XZB40,5# | — | |
| 23670 — Injector Assy | ||||
| 23670-79035 |
Injector Assy
2006-08 → 2007-08
ended
|
N04C XZB5# | — | |
| 23670-79035 note |
Injector Assy
2007-08 → 2008-03
ended
|
N04C XZB50 STD GEN | — | |
| 23670-79035 note |
Injector Assy
2007-08 → 2008-04
ended
|
N04C XZB5# IV;N04C XZB50 +1 | — | |
| 23670-79036 |
Injector Assy
2008-04 → 2009-08
ended
|
N04C XZB40,5# | — | |
| 23670-79085 |
Injector Assy
2009-08 → 2011-04
ended
|
N04C XZB50 IV | — | |
| 23670-79086 |
Injector Assy
2011-04 → 2013-11
ended
|
N04C XZB50 IV | — | |
| 23670-79095 |
Injector Assy
2009-08 → 2011-04
ended
|
N04C XZB40,5# ARL,GEN,TAIW | — | |
| 23670-79096 |
Injector Assy
2011-04 → 2015-01
ended
|
N04C XZB40,5# ARL,GEN,TAIW | — | |
| 23670-E9280 |
Injector Assy
2015-01 → 2015-08
ended
|
N04C XZB40,50 LHD GEN | — | |
| 23670-E9281 |
Injector Assy
2015-08 → 2016-08
ended
|
N04C XZB40,50 LHD GEN | — | |
| 23670-E9282 |
Injector Assy
2016-08 → 2017-02
ended
|
N04C XZB40,50 LHD GEN | — | |
| 23670-E9290 |
Injector Assy
2015-01 → 2015-08
ended
|
N04C XZB40,59 HRF;N04C XZB50 +1 | — | |
| 23670-E9291 |
Injector Assy
2015-08 → 2016-08
ended
|
N04C XZB40,59 HRF;N04C XZB50 +1 | — | |
| 23670-E9292 |
Injector Assy
2016-08 → 2017-02
ended
|
N04C XZB40,59 HRF;N04C XZB50 +1 | — | |
| 23670A — Ring, O(FOR INJECTOR ASSY) | ||||
| 90033-01101 |
Ring, O(FOR INJECTOR ASSY)
2009-04 → 2009-08
ended
|
N04C XZB40,5# | — | |
| 90301-19005 |
Ring, O(FOR INJECTOR ASSY)
2006-08 → 2009-04
ended
|
N04C XZB40,59;N04C XZB50 IV;N04C +2 | — | |
| 90301-19005 |
Ring, O(FOR INJECTOR ASSY)
2009-08 → 2015-01
ended
|
N04C XZB40,5# ARL,GEN,TAIW | — | |
| 90301-19005 |
Ring, O(FOR INJECTOR ASSY)
2009-08 → 2013-11
ended
|
N04C XZB50 IV | — | |
| 90301-19005 |
Ring, O(FOR INJECTOR ASSY)
2006-08 → 2008-03
ended
|
N04C XZB50 STD GEN | — | |
| 15518-E0010 |
Ring, O(FOR INJECTOR ASSY)
2016-03 → 2017-02
ended
|
N04C XZB40,5# | — | |
| SZ301-19001 |
Ring, O(FOR INJECTOR ASSY)
2015-01 → 2016-02
ended
|
N04C XZB40,5# | — | |
| 23681 — Seal, Nozzle Holder | ||||
| 23681-17010 |
Seal, Nozzle Holder
1996-05 → 1999-07
ended
|
15BFT BB43,5# | — | |
| 23681-17010 |
Seal, Nozzle Holder
1999-07 → 2004-08
ended
|
15BFTE BB5#;15BFT BB50 STD +3 | — | |
| 23681-17010 |
Seal, Nozzle Holder
1999-07 → 2002-11
ended
|
15BFT BB50 CHI | — | |
| 23681-17010 |
Seal, Nozzle Holder
1999-07 → 2001-05
ended
|
15BFT BB50 WOC 6F;15BFT +4 | — | |
| 23681-17010 |
Seal, Nozzle Holder
1999-07 → 2001-08
ended
|
15BFT BB50 WOC 5F;15BFT +6 | — | |
| 23681-17010 |
Seal, Nozzle Holder
2004-08 → 2006-08
ended
|
15BFTE BB5# | — | |
| 23681-17010 |
Seal, Nozzle Holder
2004-08 → 2015-01
ended
|
15BFT BB50 | — | |
| 23681-78010 |
Seal, Nozzle Holder
2006-08 → 2008-03
ended
|
N04C XZB50 STD GEN | — | |
| 23681-78010 |
Seal, Nozzle Holder
2006-08 → 2009-08
ended
|
N04C XZB50 WOC CBU | — | |
| 23681-78010 |
Seal, Nozzle Holder
2006-08 → 2011-07
ended
|
N04C XZB40,59;N04C XZB50 IV;N04C +3 | — | |
| S2307-41070 |
Seal, Nozzle Holder
2011-07 → 2013-11
ended
|
N04C XZB50 IV | — | |
| S2307-41070 |
Seal, Nozzle Holder
2011-07 → 2015-01
ended
|
N04C XZB40,5# ARL,GEN,TAIW | — | |
| S2307-41070 |
Seal, Nozzle Holder
2015-01 → —
|
N04C XZB40,5# | — | |
| 23695 — Clamp, Nozzle Holder, NO.1 | ||||
| 23695-58010 |
Clamp, Nozzle Holder, NO.1
1996-05 → 1999-07
ended
|
15BFT BB43,5# | — | |
| 23695-58010 |
Clamp, Nozzle Holder, NO.1
1999-07 → 2001-05
ended
|
15BFT BB50 WOC 6F;15BFT +4 | — | |
| 23695-58010 |
Clamp, Nozzle Holder, NO.1
1999-07 → 2001-08
ended
|
15BFT BB50 WOC 5F;15BFT +6 | — | |
| 23695-58010 |
Clamp, Nozzle Holder, NO.1
1999-07 → 2002-11
ended
|
15BFT BB50 CHI | — | |
| 23695-58010 |
Clamp, Nozzle Holder, NO.1
1999-07 → 2004-08
ended
|
15BFTE BB5#;15BFT BB50 STD +3 | — | |
| 23695-58010 |
Clamp, Nozzle Holder, NO.1
2004-08 → 2006-08
ended
|
15BFTE BB5# | — | |
| 23695-58010 |
Clamp, Nozzle Holder, NO.1
2004-08 → 2015-01
ended
|
15BFT BB50 | — | |
| 23695-78020 |
Clamp, Nozzle Holder, NO.1
2006-08 → 2008-03
ended
|
N04C XZB50 STD GEN | — | |
| 23695-78020 |
Clamp, Nozzle Holder, NO.1
2006-08 → 2011-07
ended
|
N04C XZB40,59;N04C XZB50 IV;N04C +3 | — | |
| 23695-78020 |
Clamp, Nozzle Holder, NO.1
2006-08 → 2009-08
ended
|
N04C XZB50 WOC CBU | — | |
| S1119-51140 |
Clamp, Nozzle Holder, NO.1
2011-07 → 2013-11
ended
|
N04C XZB50 IV | — | |
| S1119-51140 |
Clamp, Nozzle Holder, NO.1
2011-07 → 2015-01
ended
|
N04C XZB40,5# ARL,GEN,TAIW | — | |
| S1119-51140 |
Clamp, Nozzle Holder, NO.1
2015-01 → —
|
N04C XZB40,5# | — | |
| 23760 — Pipe Assy, Nozzle Leakage | ||||
| 23760-56040 |
Pipe Assy, Nozzle Leakage
1993-01 → 1999-07
ended
|
3B BB40 | — | |
| 23760-56060 |
Pipe Assy, Nozzle Leakage
1993-01 → 1999-07
ended
|
14B BB42 | — | |
| 23761-17010 |
Pipe Assy, Nozzle Leakage
1993-01 → 1999-07
ended
|
1HZ# HZB50 | — | |
| 23761-58010 |
Pipe Assy, Nozzle Leakage
1996-05 → 1999-05
ended
|
15BFT BB43,5# | — | |
| 23761-58011 |
Pipe Assy, Nozzle Leakage
1999-05 → 1999-07
ended
|
15BFT BB43,5# | — | |
| 23760-56060 |
Pipe Assy, Nozzle Leakage
1999-07 → 2001-08
ended
|
14B BB42 22S;14B BB42 +6 | — | |
| 23760-56060 |
Pipe Assy, Nozzle Leakage
1999-07 → 2004-08
ended
|
14B WOC BB42 WC +11 | — | |
| 23761-17010 |
Pipe Assy, Nozzle Leakage
1999-07 → 2004-08
ended
|
1HZ .SRF HZB50 WC +11 | — | |
| 23761-17010 |
Pipe Assy, Nozzle Leakage
1999-07 → 2002-11
ended
|
1HZ HZB50 ARL | — | |
| 23761-17010 |
Pipe Assy, Nozzle Leakage
1999-07 → 2001-08
ended
|
1HZ HZB50 RHD SRF;1HZ +8 | — | |
| 23761-58011 |
Pipe Assy, Nozzle Leakage
1999-07 → 2002-11
ended
|
15BFT BB50 CHI | — | |
| 23761-58011 |
Pipe Assy, Nozzle Leakage
1999-07 → 2001-05
ended
|
15BFT BB50 WOC 6F;15BFT +4 | — | |
| 23761-58011 |
Pipe Assy, Nozzle Leakage
1999-07 → 2004-08
ended
|
15BFTE BB5#;15BFT BB50 STD +3 | — | |
| 23761-58011 |
Pipe Assy, Nozzle Leakage
1999-07 → 2001-08
ended
|
15BFT BB50 WOC 5F;15BFT +6 | — | |
| 23708-78010 |
Pipe Assy, Nozzle Leakage
2006-08 → 2008-03
ended
|
N04C XZB50 STD GEN | — | |
| 23708-78010 |
Pipe Assy, Nozzle Leakage
2006-08 → 2009-08
ended
|
N04C XZB50 WOC CBU | — | |
| 23708-78010 |
Pipe Assy, Nozzle Leakage
2006-08 → 2011-07
ended
|
N04C XZB40,59;N04C XZB50 IV;N04C +3 | — | |
| 23760-56060 |
Pipe Assy, Nozzle Leakage
2004-08 → 2011-08
ended
|
14B BB42 LHD HRF | — | |
| 23760-56060 |
Pipe Assy, Nozzle Leakage
2004-08 → 2015-01
ended
|
14B BB42 RHD;14B BB42 +2 | — | |
| 23761-17010 |
Pipe Assy, Nozzle Leakage
2004-08 → 2015-01
ended
|
1HZ HZB50 | — | |
| 23761-58011 |
Pipe Assy, Nozzle Leakage
2004-08 → 2006-08
ended
|
15BFTE BB5# | — | |
| 23761-58011 |
Pipe Assy, Nozzle Leakage
2004-08 → 2015-01
ended
|
15BFT BB50 | — | |
| S2308-12630 |
Pipe Assy, Nozzle Leakage
2011-07 → 2013-11
ended
|
N04C XZB50 IV | — | |
| S2308-12630 |
Pipe Assy, Nozzle Leakage
2011-07 → 2015-01
ended
|
N04C XZB40,5# ARL,GEN,TAIW | — | |
| 23760-56060 |
Pipe Assy, Nozzle Leakage
2015-01 → —
|
14B BB42 | — | |
| 23761-17010 |
Pipe Assy, Nozzle Leakage
2015-01 → —
|
1HZ HZB50 | — | |
| S2308-12630 |
Pipe Assy, Nozzle Leakage
2015-01 → —
|
N04C XZB40,5# | — | |
| 23760A — Gasket | ||||
| 90430-13002 |
Gasket
1996-05 → 1999-07
ended
|
15BFT BB43,5# | — | |
| 90430-13002 |
Gasket
1999-07 → 2001-05
ended
|
15BFT BB50 WOC 6F;15BFT +4 | — | |
| 90430-13002 |
Gasket
1999-07 → 2004-08
ended
|
15BFTE BB5#;15BFT BB50 STD +3 | — | |
| 90430-13002 |
Gasket
1999-07 → 2001-08
ended
|
15BFT BB50 WOC 5F;15BFT +6 | — | |
| 90430-13002 |
Gasket
1999-07 → 2002-11
ended
|
15BFT BB50 CHI | — | |
| 90032-09030 |
Gasket
2006-08 → 2007-06
ended
|
N04C XZB5# | — | |
| 90032-09032 |
Gasket
2007-06 → 2015-01
ended
|
N04C XZB40,59;N04C XZB50 (20S,21S) +1 | — | |
| 90032-09032 |
Gasket
2007-06 → 2013-11
ended
|
N04C XZB50 IV | — | |
| 90032-09032 |
Gasket
2007-06 → 2009-08
ended
|
N04C XZB50 WOC CBU | — | |
| 90032-09032 |
Gasket
2007-06 → 2008-03
ended
|
N04C XZB50 STD GEN | — | |
| 90430-13002 |
Gasket
2004-08 → 2015-01
ended
|
15BFT BB50 | — | |
| 90430-13002 |
Gasket
2004-08 → 2006-08
ended
|
15BFTE BB5# | — | |
| SZ209-08024 |
Gasket
2015-01 → —
|
N04C XZB40,5# | — | |
| 23760B — Bolt, Union(FOR NOZZLE LEAKAGE PIPE) | ||||
| 21811-E0060 |
Bolt, Union(FOR NOZZLE LEAKAGE PIPE)
2012-10 → 2013-11
ended
|
N04C XZB50 IV | — | |
| 21811-E0060 |
Bolt, Union(FOR NOZZLE LEAKAGE PIPE)
2012-10 → 2015-01
ended
|
N04C XZB40,5# ARL,GEN,TAIW | — | |
| 90034-01009 |
Bolt, Union(FOR NOZZLE LEAKAGE PIPE)
2006-08 → 2008-03
ended
|
N04C XZB50 STD GEN | — | |
| 90034-01009 |
Bolt, Union(FOR NOZZLE LEAKAGE PIPE)
2006-08 → 2008-05
ended
|
N04C XZB40,59;N04C XZB50 IV;N04C +2 | — | |
| 90034-01019 |
Bolt, Union(FOR NOZZLE LEAKAGE PIPE)
2008-05 → 2009-08
ended
|
N04C XZB50 WOC CBU | — | |
| 90034-01019 |
Bolt, Union(FOR NOZZLE LEAKAGE PIPE)
2008-05 → 2012-10
ended
|
N04C XZB40,5# WC;N04C XZB50 +2 | — | |
| 21811-E0060 |
Bolt, Union(FOR NOZZLE LEAKAGE PIPE)
2015-01 → —
|
N04C XZB40,5# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
