Toyota Coaster
2017-01 → present · chassis BB60,BZB60,70,GDB##,HZB60,70,TRB60,70,XZB60,70,80 · catalogue 811240 · General
Supported model
Data version 2025-01
Vacuum Piping
31 part groups · 8 illustrations
Part groups
| PNC | Description |
|---|---|
| 17308B | Hose Sub-assy, Vacuum |
| 17341P | Hose, Air |
| 17578B | Clamp, Pipe |
| 17630 | Valve Assy, Air Control |
| 17650 | Valve Assy, Vacuum Switching |
| 17696 | Bracket, Gas Filter |
| 17810A | Filter Assy, Air |
| 22233 | Hose, Lpg Auxiliary Air Valve, NO.1 |
| 22233A | Clip(FOR LPG AUXILIARY AIR VALVE NO.1) |
| 22270K | Valve Assy, Lpg Idle Speed Control |
| 22278A | Gasket, Lpg Idle Speed Control Valve |
| 23265 | Filter, Gas, NO.1 |
| 23265C | Filter, Gas |
| 23285A | Valve, Check, NO.1 |
| 23288 | Jet, NO.1 |
| 23289 | Jet, NO.2 |
| 25706 | Pipe Sub-assy, Vacuum Transmitting, NO.1 |
| 25733A | Pipe, Vacuum, NO.1 |
| 25734 | Pipe, Vacuum, NO.2 |
| 25760 | Hose Assy, Vacuum Transmitting |
| 25760D | Hose Assy, Vacuum Transmitting, NO.4 |
| 25761B | Hose, Vaccum Transmitting, NO.1 |
| 25771B | Hose, Vaccum Transmitting, NO.2 |
| 25781A | Hose, Vacuum Transmitting, NO.3 |
| 257A1 | Hose, Vacuum Transmitting, NO.5 |
| 25804 | Valve Set, Vacuum Control |
| 25860 | Valve Assy, Vacuum Switching, NO.1 |
| 25860D | Valve Assy, Vacuum Switching, NO.2 |
| 25894 | Filter, NO.1 |
| 88031R | Actuator Set, Idle-up |
| 89639E | Clamp |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
