Toyota Coaster
2017-01 → present · chassis BB60,BZB60,70,GDB##,HZB60,70,TRB60,70,XZB60,70,80 · catalogue 811240 · General
Supported model
Data version 2025-01
Front Bumper & Bumper Stay
11 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 52115A | Support, Front Bumper Side, RH |
| 52116A | Support, Front Bumper Side, LH |
| 52119A | Cover, Front Bumper |
| 52127C | Cover, Front Bumper Hole |
| 52141D | Stay, Front Bumper, RH |
| 52142C | Stay, Front Bumper, LH |
| 52161T | Piece, Front Bumper |
| 52437C | Cover, Front Bumper Guard |
| 52535D | Retainer, Front Bumper Side |
| 53112D | Grille, Radiator, Lower RH |
| 53113D | Grille, Radiator, Lower LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
