Toyota Coaster
2017-01 → present · chassis BB60,BZB60,70,GDB##,HZB60,70,TRB60,70,XZB60,70,80 · catalogue 811240 · General
Supported model
Data version 2025-01
Front Panel & Windshield Glass
25 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 53301F | Panel Sub-assy, Front |
| 53801L | Extension, Front Fender, RH |
| 53802L | Extension, Front Fender, LH |
| 55211B | Silencer, Front Panel |
| 55211E | Silencer, Front Panel |
| 55241 | Silencer, Front Panel Side, NO.1 RH |
| 55242 | Silencer, Front Panel Side, NO.1 LH |
| 55243A | Silencer, Front Panel Side, NO.2 RH |
| 55244A | Silencer, Front Panel Side, NO.2 LH |
| 55245 | Silencer, Front Panel Side, NO.3 RH |
| 55246 | Silencer, Front Panel Side, NO.3 LH |
| 56111 | Glass, Windshield |
| 56114C | Retainer, Windshield Glass |
| 56115F | Stopper, Windshield Glass |
| 56116E | Stopper, Windshield Glass, NO.2 |
| 56119 | Seal, Windshield Glass |
| 61101C | Panel Sub-assy, Cowl Side, RH |
| 61104C | Panel Sub-assy, Cowl Side, LH |
| 64818A | Spacer, Back Window Glass |
| 75531E | Moulding, Windshield, Outside Upper |
| 75535E | Moulding, Windshield, Outside Lower |
| 75896N | Tape, Moulding, NO.1 |
| 75911B | Tape, Black Out Hood |
| 75913B | Tape, Black Out Fender, RH |
| 75914B | Tape, Black Out Fender, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
