Toyota Coaster
2017-01 → present · chassis BB60,BZB60,70,GDB##,HZB60,70,TRB60,70,XZB60,70,80 · catalogue 811240 · General
Supported model
Data version 2025-01
Front Floor Panel & Front Floor Member
110 part groups · 7 illustrations
Part groups
| PNC | Description |
|---|---|
| 51771J | Step, RH |
| 51774C | Cover, Step Plate, LH |
| 53711C | Apron, Front Fender, RH |
| 53712C | Apron, Front Fender, LH |
| 53896C | Shield, Side Floor Apron, Front LH |
| 55123 | Reinforcement, Steering Support |
| 55141A | Bracket, Foot Rest Mounting |
| 55149 | Bracket, Dash Wiring Harness |
| 55150A | Bracket Assy, Pedal |
| 55155A | Bracket, Accelerator Pedal |
| 55161B | Bracket, Heater Mounting, RH |
| 57011 | Member Sub-assy, Floor, RH |
| 57012 | Menber Sub-assy |
| 57021C | Strength Sub-assy, Anchor Side, NO.1 |
| 57021D | Strength Sub-assy, Anchor Side, NO.2 |
| 57023C | Strength Sub-assy, Anchor Side, NO.1 |
| 57023D | Strength Sub-assy, Anchor Side, NO.2 |
| 57101C | Crossmember Sub-assy, Floor, NO.1 |
| 57102A | Crossmenber Sub-assy, Floor, NO.2 |
| 57424B | Reinforcement, Front Floor Under, Inner LH |
| 58015B | Panel Sub-assy, Front Floor Housing, Front RH |
| 58016B | Panel Sub-assy, Front Floor Housing, Front LH |
| 58017 | Panel Sub-assy, Front Floor Housing, Rear RH |
| 58018B | Panel Sub-assy, Front Floor Housing, Rear LH |
| 58103C | Reinforcement Sub-assy, Front Floor, Front |
| 58108C | Panel Sub-assy, Footrest |
| 58111A | Pan, Front Floor, RH |
| 58112A | Panel, Front Floor, LH |
| 58113A | Panel, Front Floor, Center |
| 58115A | Reinforcement, Front Floor Panel |
| 58116B | Panel, Front Floor Rear Upper Side, RH |
| 58116C | Panel, Front Floor Rear Upper Side, RH |
| 58118B | Reinforcement, Front Floor Panel, NO.2 |
| 58119 | Plate, Front Floor Side, Front |
| 58123A | Support, Shift & Select Lever |
| 58123B | Panel, Front Floor, Center LH |
| 58126B | Panel, Front Floor Rear Upper Side, LH |
| 58127B | Gusset, Shift & Select Lever Support |
| 58131C | Bracket, Reserve Tank Service Hole Cover |
| 58132B | Panel, Front Floor, Center |
| 58139C | Bracket, Harness Clamp |
| 58149A | Plate, Front Floor Side, Rear LH |
| 58157A | Stay, Front Floor Housing, Rear RH |
| 58158A | Stay, Front Floor Housing, Rear LH |
| 58169A | Retainer, Rear Heater Mounting |
| 58171 | Reinforcement, Parking Brake Base |
| 58172B | Bracket, Computer Mounting, NO.3 |
| 58173B | Angle, Front Floor Side, RH |
| 58174A | Angle Sub-assy, Front Floor Side, LH |
| 58175A | Reinforcement, Parking Brake Base, NO.1 |
| 58177A | Extension, Front Floor Panel, RH |
| 58178A | Extension, Front Floor Panel, LH |
| 58179B | Bracket, Accelerator Cable Clamp |
| 58181B | Bracket, Front Seat Inside Mounting, Front RH |
| 58182 | Bracket, Front Seat Inside Mounting, Front LH |
| 58183E | Bracket, Front Seat Mounting, Outside |
| 58184D | Bracket, Front Seat Mounting, Outside |
| 58187B | Bracket, Accelerator Pedal Rod |
| 58188A | Bracket, Accelerator Pedal Stopper |
| 58191 | Footrest, Front Floor |
| 58193 | Bracket, Instrument Panel Brace Mounting |
| 58194C | Bracket, Instrument Panel Brace Mounting, LH |
| 58197C | Plate, Vacuum Tube Bracket, RH |
| 58209C | Cover Sub-assy, Heater Air Intake |
| 58217B | Plate, Front Floor |
| 58227B | Plate, Front Floor Panel Side, RH |
| 58243D | Panel, Floor Side, Rear RH |
| 58244D | Panel, Floor Side, Rear LH |
| 58251A | Reinforcement, Front Seat, Front RH |
| 58256B | Bracket, Air Cleaner, Rear |
| 58256D | Bracket, Front Floor Harness |
| 58261B | Reinforcement, Front Seat, Front LH |
| 58269B | Cover, Parking Brake Cable, RH |
| 58275E | Bracket, Wire Harness Protector |
| 58279B | Cover, Parking Brake Cable, LH |
| 58286 | Boot, Shift & Select Lever, NO.1 |
| 58294A | Bracket, Floor Shift Link, LH |
| 58295C | Bracket, Floor Shift Lever, NO.1 |
| 58316J | Plate, Footrest, Rear |
| 58396E | Bracket, Wire Harness Clamp |
| 58410 | Cover, Engine Service Hole |
| 58420 | Cover Assy, Engine Service Hole, NO.2 |
| 58431D | Silencer, Engine Room Side, Front RH |
| 58432B | Silencer, Engine Room Side, Rear RH |
| 58433A | Silencer, Engine Room Side End |
| 58441D | Silencer, Enging Room Side, Front LH |
| 58442B | Silencer, Enging Room Side, Rear LH |
| 58444B | Packing, Engine Sub Cover |
| 58492A | Packing, Relay Block Hole Cover |
| 58493 | Retainer, Engine Cover, NO.3 |
| 58575E | Pad, Front Floor, Rear NO.1 |
| 58701A | Panel Sub-assy, Engine Service Cover, Front |
| 58704C | Hook Sub-assy, Engine Service Cover Catch, Rear |
| 58709B | Catch Sub-assy, Engine Service Cover |
| 58724A | Cushion, Engine Service Cover, NO.2 |
| 58726B | Plate, Engine Service Cover, Front Upper |
| 58728A | Plate, Engine Service Cover, NO.2 |
| 58733C | Weatherstrip, Engine Service Cover, Front |
| 58734B | Weatherstrip, Engine Service Cover, Rear |
| 58755B | Handle, Engine Service Cover Catch |
| 58760A | Cover Assy, Regulator Service Hole |
| 58848A | Cover, Shift Lever Hole |
| 59263A | Hook, Engine Cover Lock |
| 65579C | Bracket, Side Panel Frame |
| 74715C | Retainer, Extinguisher, NO.1 |
| 76621A | Mudguard, Front Body, Front RH |
| 76622A | Mudguard, Front Body, Front LH |
| 76623 | Mudguard, Front Body, Rear RH |
| 76624 | Mudguard, Front Body, Rear LH |
| 89987E | Bracket, Computer, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
