Toyota Coaster
2017-01 → present · chassis BB60,BZB60,70,GDB##,HZB60,70,TRB60,70,XZB60,70,80 · catalogue 811240 · General
Supported model
Data version 2025-01
Center Door Panel & Glass
58 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 61084 | Rail Sub-assy, Center Door |
| 62267U | Dam, Side Window Adhesive |
| 62267V | Dam, Side Window Adhesive |
| 62384Q | Cap, Side Window Clip |
| 62925A | Weatherstrip, Glide Door Side |
| 62927 | Weatherstrip, Glide Door Outer |
| 67003F | Panel Sub-assy, Center Door, Front |
| 67003G | Panel Sub-assy, Slide Door |
| 67004C | Panel Sub-assy, Center Door, Rear |
| 67087 | Plate Sub-assy, Center Door Dust Seal, Front |
| 67088 | Plate Sub-assy, Center Door Dust Seal, Rear |
| 67207D | Cover Sub-assy, Center Door, Outer |
| 67219 | Bush, Center Door Upper Bearing Case |
| 67238 | Cushion, Center Door |
| 67253 | Piece, Center Door Guide |
| 67254 | Stopper, Center Door, Inside NO.1 |
| 67261B | Case, Center Door Guide |
| 67266A | Stopper, Center Door Rail |
| 67268 | Rollar, Rear Door, Upper |
| 67279 | Cushion, Center Door Guide |
| 67680A | Trim Assy, Gride Door |
| 67690 | Trim Assy, Gride Door, Lower |
| 67745 | Moulding, Center Door Trim |
| 67841A | Cover, Glide Door Service Hole |
| 67855C | Weatherstrip, Center Door Front |
| 67856C | Weatherstrip, Center Door, Rear |
| 67857D | Weatherstrip, Center Door, Center |
| 67859F | Cover, Glide Door Lower Hole |
| 67867H | Retainer, Door Weatherstrip, RH |
| 67869G | Clip, Door Weatherstrip |
| 67871B | Weatherstrip, Glide Door |
| 67874B | Weatherstrip, Center Door, Upper NO.2 |
| 67895 | Seal, Center Door Dust |
| 67917E | Plate, Center Door Scuff |
| 68111 | Glass, Center Door |
| 68112 | Glass, Center Door, NO.2 |
| 68113C | Glass, Glide Door |
| 68165B | Moulding, Glide Door Glass |
| 68217F | Pin, Center Door Fix Window, NO.1 |
| 68217G | Pin, Center Door Fix Window, NO.2 |
| 68218D | Bush, Center Door Fix Window |
| 68294F | Dam, Side Window Adhesive |
| 68618B | Retainer, Door Check Pin |
| 68630B | Check Assy, Glide Door |
| 68630C | Pin(FOR GLIDE DOOR CHECK) |
| 68705 | Hinge Sub-assy, Center Door, Outer NO.1 |
| 68706 | Hinge Sub-assy, Center Door, Outer NO.1 |
| 68706A | Hinge Sub-assy, Center Door, Outer NO.1 |
| 68709 | Case Sub-assy, Center Door Upper Bearing |
| 68723 | Pad, Door Upper Hinge |
| 68737 | Case, Center Door Lower Bearing |
| 68739 | Ball, Center Door Lower Bearing |
| 69288B | Cover, Front Slide Door Inside Handle |
| 74642 | Grip, Glide Door Assist |
| 74656S | Cover, Glide Door Assist Grip |
| 75396G | Clip, Outside Moulding, NO.2 |
| 75895L | Tape, Moulding, NO.1 |
| 75896M | Tape, Moulding, NO.2 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
