Toyota Coaster
2017-01 → present · chassis BB60,BZB60,70,GDB##,HZB60,70,TRB60,70,XZB60,70,80 · catalogue 811240 · General
Supported model
Data version 2025-01
Seat Belt
48 part groups · 11 illustrations
Part groups
| PNC | Description |
|---|---|
| 73030A | Belt Assy, Rear Seat Lap Type, RH |
| 73040A | Belt Assy, Rear Seat Lap Type, LH |
| 73135A | Cover, Shoulder Belt Anchor, RH |
| 73136A | Cover, Shoulder Belt Anchor, LH |
| 73178A | Cap, Seat Belt Anchor Cover |
| 73178C | Cap, Seat Belt Anchor Cover |
| 73178G | Cap, Seat Belt Anchor Cover |
| 73179A | Cap, Seat Belt Anchor Cover, LH |
| 73187A | Guide, Rear Seat Shoulder Belt |
| 73210 | Belt Assy, Front Seat Outer, RH |
| 73219 | Stopper, Tongue Plate |
| 73220 | Belt Assy, Front Seat Outer, LH |
| 73223B | Cover, Front Seat Belt Retractor, RH |
| 73224 | Cover, Front Seat Belt Retractor, LH |
| 73230 | Belt Assy, Front Seat Inner, RH |
| 73233 | Cover, Lap Belt Outer Anchor |
| 73237A | Cover, Shoulder Belt Anchor |
| 73237B | Cover, Shoulder Belt Anchor |
| 73239A | Cover, Rear Seat Shoulder Belt, RH |
| 73240 | Belt Assy, Front Seat Inner, LH |
| 73302 | Belt Sub-assy, Rear Seat Outer |
| 73303 | Belt Sub-assy, Sub Seat, Outer |
| 73306 | Belt Sub-assy Seat, Inner |
| 73307 | Belt Sub-assy, Rear Seat, Inner |
| 73308 | Belt Sub-assy, Sub Seat, Inner |
| 73330 | Belt Assy, Rear Seat Lap Type, RH |
| 73330G | Belt Assy, RR Seat Lap Type |
| 73330H | Belt Assy, RR Seat Lap Type |
| 73340 | Belt Assy, Rear Seat Lap Type, LH |
| 73343 | Guide, Rear Seat Shoulder Belt, RH |
| 73344 | Guide, Rear Seat Shoulder Belt, LH |
| 73350C | Belt Assy, Rear Seat, Outer Center |
| 73360B | Belt Assy, Rear Seat, Outer |
| 73370B | Belt Assy, Rear Seat, Outer |
| 73373A | Cover, Rear Seat Shoulder Belt, RH |
| 73375 | Cover, Rear Seat Shoulder Belt, LH |
| 73380 | Belt Assy, Rear Seat 3 Point Type, Inner, RH |
| 73380A | Belt Assy, Rear Seat, Inner |
| 73380D | Belt Assy, Rear Seat, Inner |
| 73380F | Belt Assy, RR Seat, Inner |
| 73389 | Cover, Rear Seat Shoulder Belt, LH |
| 73390 | Belt Assy, Rear Seat 3 Point Type, Inner, LH |
| 73390A | Belt Assy, Rear Seat, Inner |
| 73470 | Belt Assy, Rear Seat, Outer |
| 73580 | Belt Assy, Rear NO.2 Seat, Inner RH |
| 73580B | Belt Assy, Rear Seat, Inner RH |
| 73590 | Belt Assy, Rear NO.2 Seat, Inner LH |
| 73590A | Belt Assy, Rear Seat, Inner LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
