Toyota Coaster (CHINA)
2000-12 → 2014-03 · chassis BB5#,RZB5#,TRB53,XZB53 · catalogue 814310 · General
Discontinued model
Data version 2014-01
Instrument Panel & Glove Compartment
41 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 55301 | Panel Sub-assy, Instrument |
| 55305B | Reinforcement Sub-assy, Instrument Panel, NO.1 |
| 55306C | Reinforcement Sub-assy, Instrument Panel, NO.2 |
| 55307D | Reinforcement Sub-assy, Instrument Panel, NO.3 |
| 55308C | Bracket Sub-assy, Instrument Panel, Center |
| 55312A | Clip, Instrument Panel |
| 55316 | Spacer, Instrument Panel, NO.2 |
| 55342A | Brace, Instrument Panel TO Cowl, NO.2 |
| 55343B | Brace, Instrument Panel TO Cowl, Center |
| 55345B | Brace, Instrument Panel TO Cowl, NO.4 |
| 55351A | Brace, Instrument Panel TO Floor |
| 55352A | Brace, Instrument Panel TO Floor, NO.2 |
| 55358F | Protector, Edge |
| 55358H | Protector, Instrument Panel |
| 55403 | Hood Sub-assy, Meter |
| 55407C | Cover Sub-assy, Instrument, Lower |
| 55411G | Panel, Instrument Cluster Finish, NO.1 |
| 55412D | Panel, Instrument Cluster Finish, Center |
| 55425A | Bracket, Meter Hood Set |
| 55432D | Panel, Instrument Panel Finish, Lower NO.1 |
| 55441 | Box, Instrument Panel |
| 55446A | Base, Switch Hole, NO.1 |
| 55477A | Bezel, Cigarette Lighter Hole |
| 55521C | Cover, Stereo Opening |
| 55521F | Cover, Stereo Opening, NO.2 |
| 55524 | Cover, Switch Bace Hole |
| 55524B | Cover, Switch Base Hole |
| 55524C | Cover, Switch Base Hole, NO.4 |
| 55539 | Cover, Spare Switch Hole |
| 55547 | Cover, Remote Control Mirror Hole |
| 55548A | Cover, Instrument Panel Hole |
| 55549B | Cover, Instrument Panel Hole, NO.2 |
| 55604A | Holder Sub-assy, Instrument Panel Cup |
| 55617A | Cover, Throttle Knob Hole |
| 55650 | Register Assy, Instrument Panel, NO.1 |
| 55660 | Register Assy, Instrument Panel, NO.2 |
| 55670 | Register Assy, Instrument Panel, NO.3 |
| 55950 | Nozzle Assy, Defroster |
| 55961 | Nozzle, Side Defroster, NO.1 |
| 55962 | Nozzle, Side Defroster, NO.2 |
| 55972 | Duct, Side Defroster Nozzle, NO.2 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
