Toyota Coaster (CHINA)
2000-12 → 2014-03 · chassis BB5#,RZB5#,TRB53,XZB53 · catalogue 814310 · General
Discontinued model
Data version 2014-01
Heating & Air Conditioning - Control & Air Duct
42 part groups · 8 illustrations
Part groups
| PNC | Description |
|---|---|
| 55084E | Duct Sub-assy, Heater TO Register, NO.1 |
| 55085 | Duct Sub-assy, Heater TO Register, NO.2 |
| 55519 | Plate, Heater Control Name |
| 55845A | Duct, Heater TO Register, NO.3 |
| 55905A | Knob, Heater Control |
| 55906A | Cable Sub-assy, Defroster Damper Control |
| 55907A | Cable Sub-assy, Water Valve Control |
| 55907F | Cable Sub-assy, Water Valve Control |
| 55908A | Cable Sub-assy, Air Inlet Damper Control |
| 55910 | Control Assy, Heater OR Boost Ventilator |
| 63610 | Register Assy, Air Outlet, NO.1 |
| 63620 | Register Assy, Air Outlet, NO.2 |
| 63630A | Register Assy, Air Duct, NO.3 |
| 63855C | Retainer, Roof Ventilator Duct |
| 63911 | Duct, Cooler, Outer RH |
| 63912 | Duct, Cooler, Outer LH |
| 63915 | Duct, Cooler, Inner NO.1 RH |
| 63925 | Duct, Cooler, Inner NO.1 LH |
| 63927A | Cover, Cooler Duct End, NO.1 |
| 63928 | Cover, Cooler Duct End, NO.2 |
| 63950 | Duct Assy, Cooler, Inner NO.2 RH |
| 63960 | Duct Assy, Cooler, Inner NO.2 LH |
| 63972 | Moulding, Cooler Duct Side, NO.1 RH |
| 63973 | Moulding, Cooler Duct Side, NO.2 RH |
| 63974 | Moulding, Cooler Duct Side, NO.3 RH |
| 63975 | Moulding, Cooler Duct Side, NO.4 RH |
| 63982 | Moulding, Cooler Duct Side, NO.1 LH |
| 87106K | Servo Sub-assy, Damper(FOR AIRMIX) |
| 87114C | Cover, Heater |
| 87138B | Resistor, Heater Blower |
| 87190 | Switch Assy, Temperature Control |
| 87210 | Damper Assy, Air |
| 87316 | Bracket, Heater Relay, NO.1 |
| 88430A | Duct Assy, Air, NO.1 |
| 88430B | Duct Assy, Air, NO.2 |
| 88430C | Duct Assy, Air, NO.3 |
| 88430D | Duct Assy, Air, NO.4 |
| 88568A | Filter, Air |
| 88580 | Damper Assy, Air |
| 88630K | Relay Assy |
| 88635C | Resistor, Cooler Air Duct, NO.1 |
| 88650B | Amplifier Assy, Airconditioner |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
