Factory parts data · Europe

Toyota Coaster (CHINA)

2013-01 → present · chassis GRB53,TRB53,XZB53 · catalogue 814320 · General

Discontinued model Data version 2020-07

Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Abs & Vsc

11 part groups · 2 illustrations

Illustrations

Figure 84E039B

84E039B 2013-01 → 2019-11

Figure 84K923A

84K923A 2019-11 → —

Part groups

PNC	Description
88263M	Relay, Abs Solenoid
88263N	Relay, Abs Motor
89183A	Sensor, Yawrate
89420E	Sensor Assy, Vacuum
89516	Wire, Skid Control Sensor
89540	Computer Assy, Skid Control
89542	Sensor, Speed, Front RH
89543	Sensor, Speed, Front LH
89544	Sensor, Skid Control
89545	Sensor, Speed, Rear RH
89546	Sensor, Speed, Rear LH

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
