Toyota Coaster Fuelcell
2021-08 → 2022-01 · chassis KMB53 · catalogue 815310 · General
Supported model
Data version 2023-05
Seat Belt
33 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 73135A | Cover, Shoulder Belt Anchor, RH |
| 73136A | Cover, Shoulder Belt Anchor, LH |
| 73137A | Cover, Shoulder Belt Anchor, Upr |
| 73178A | Cap, Seat Belt Anchor Cover |
| 73178C | Cap, Seat Belt Anchor Cover |
| 73178G | Cap, Seat Belt Anchor Cover |
| 73179A | Cap, Seat Belt Anchor Cover, LH |
| 73220 | Belt Assy, Front Seat Outer, LH |
| 73237A | Cover, Shoulder Belt Anchor |
| 73237B | Cover, Shoulder Belt Anchor |
| 73239A | Cover, Rear Seat Shoulder Belt, RH |
| 73240 | Belt Assy, Front Seat Inner, LH |
| 73317 | Cap, Rear Seat Belt, RH |
| 73318 | Cap, Rear Seat Belt, LH |
| 73343 | Guide, Rear Seat Shoulder Belt, RH |
| 73343B | Guide, Rear Seat Shoulder Belt, RH |
| 73344 | Guide, Rear Seat Shoulder Belt, LH |
| 73344A | Guide, Rear Seat Shoulder Belt, LH |
| 73350 | Belt Assy, Rear Seat Lap Type, Center |
| 73350C | Belt Assy, Rear Seat, Outer Center |
| 73360 | Belt Assy, Rear Seat 3 Point Type, Outer RH |
| 73360D | Belt Assy, Rear Seat, Outer RH |
| 73370B | Belt Assy, Rear Seat, Outer |
| 73373 | Cover, Rear Seat Shoulder Belt |
| 73373A | Cover, Rear Seat Shoulder Belt, RH |
| 73375 | Cover, Rear Seat Shoulder Belt, LH |
| 73380A | Belt Assy, Rear Seat, Inner |
| 73380D | Belt Assy, Rear Seat, Inner |
| 73380X | Belt Assy, Rear Seat, Inner RH |
| 73389 | Cover, Rear Seat Shoulder Belt, LH |
| 73390A | Belt Assy, Rear Seat, Inner |
| 73470 | Belt Assy, Rear Seat, Outer |
| 73570B | Belt Assy, Rear Seat, Outer |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
