Toyota Heavy Duty Truck

1969-03 → 2001-12 · chassis FA100,11#,FB100,FC100,DA11#,DB10# · catalogue 821210 · General

Discontinued model Data version 2002-06

Mechanical Governor

71 part groups · 4 illustrations

PNC	Description
22410	Governor Assy, Injection Pump Mechanical
22411	Lever Kit, Control
22411A	Pin, Connectiong
22411B	Shaft, Mechanical Governor
22420	Housing Sub-assy, Mechanical Governor
22420A	Seal, Oil
22421	Spring, Idling
22421B	Washer
22424	Spring, Safety
22425	Shaft Sub-assy, Governor
22427	Bolt, Connecting
22429	Ring, E
22432	Shaft
22432A	Seal, Oil
22432B	Shim
22433	Bush, Bearing
22434	Shackle
22435	Sleeve Sub-assy, Fly Weight
22435A	Bearing
22435B	Shim
22436	Pin, Connecting
22439	Pin, Shackle
22440	Flyweight Sub-assy
22440A	Key, Woodruff
22443	Spring, Start
22445	Seat Sub-assy, Spring
22446A	Bush, Bearing
22449	Stopper
22451	Adapter
22453	Spring, Adapter
22454	Washer
22455	Arm Sub-assy
22457	Shaft
22457A	Seal, Oil
22459	Nut
22460	Lever Sub-assy, Support
22460A	Link Assy, Fork
22460B	Disc, Cover
22461	Plug, Screw
22462	Washer, Seal
22464	Nut, Cap
22465	Lever Sub-assy, Adjusting
22466	Lever, Adjusting
22467	Nut, Round
22468	Cover, Plate
22468A	O, Ring
22469	Cover Sub-assy, Plate
22469A	O, Ring
22470	Lever Sub-assy, Floating
22471	Lever Sub-assy, Guide
22471A	Shaft, Lever Supporting
22472	Lever Assy, Control
22472A	Pin, Connecting
22474	Screw, Adapter
22475	Filter Sub-assy
22476	Adapter
22477	Screw, Adapter
22478	Collar
22479	Lever Sub-assy, Control
22480	Cover Sub-assy, Governor
22480B	Bolt
22480C	Bolt
22480D	Screw, Adjusting
22481	Gasket
22482	Screw, Stroke Adjusting
22483	Bushing, Bearing
22484	Bushing, Lever
22484A	Ring, O
22485	Gage Sub-assy, Governor
22486	Cap, Lever
22487	Nut, Adapter Lock

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
