Toyota Heavy Duty Truck
1969-03 → 2001-12 · chassis FA100,11#,FB100,FC100,DA11#,DB10# · catalogue 821210 · General
Discontinued model
Data version 2002-06
Rear Body Side Panel
37 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 65500 | Panel Assy, Rear Body Side, RH |
| 65550 | Post Assy, Side Panel Front End, RH |
| 65560 | Post Assy, Side Panel Front End, LH |
| 65570 | Post Assy, Side Panel Rear End, RH |
| 65580 | Post Assy, Side Panel Rear End, LH |
| 65600 | Panel Assy, Rear Body Side, LH |
| 65613 | Strip, Side Gate Hinge, Inside |
| 66001 | Semistake Set |
| 66114 | Washer, Gate Hinge Pin |
| 66115 | Pin, Gate Hinge |
| 66117 | Pin, Semistake Gate Hinge |
| 66120 | Hinge Assy, Side Gate |
| 66122 | Hinge, Side Gate, Male |
| 66126 | Hinge, Semistake Female |
| 66151 | Latch, Side Gate Female, RH |
| 66152 | Latch, Side Gate Female, LH |
| 66153 | Latch, Tail Gate Female, RH |
| 66154 | Latch, Tail Gate Female, LH |
| 66156 | Latch, Semistake Female, RH |
| 66157 | Latch, Semistake Female, LH |
| 66169 | Cap, Semistake Gate Latch Handle |
| 66314 | Protector, Rope Hook |
| 66500 | Semistake Assy, Side, RH |
| 66570 | Stay Assy, Stake, RH |
| 66575 | Handle, Stake Stay Set |
| 66576 | Spring, Stake Stay Set Handle |
| 66580 | Stay Assy, Stake, LH |
| 66590 | Bracket Assy, Stake Stay, Lower |
| 66600 | Semistake Assy, Side, LH |
| 66630 | Holder Assy, Semistake Latch Handle, RH |
| 66640 | Holder Assy, Semistake Latch Handle, LH |
| 66645 | Handle, Semistake Latch |
| 66650 | Rail Assy, Semistake, RH |
| 66660 | Rail Assy, Semistake, LH |
| 66661 | Hinge, Semistake Male |
| 66662 | Reinforcement, Semistake |
| 66663 | Strip, Semistake Inside |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
