Toyota Heavy Duty Truck
1969-03 → 2001-12 · chassis FA100,11#,FB100,FC100,DA11#,DB10# · catalogue 821210 · General
Discontinued model
Data version 2002-06
Rear Body Side Gate Lock & Tail Gate Lock
20 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 65701 | Bellcrank Sub-assy |
| 65761 | Bracket, Roller Arm, RH |
| 65762 | Bracket, Roller Arm, LH |
| 65767 | Shaft, Roller |
| 65768 | Plate, Lock(FOR ROLLER ARM BRACKET) |
| 65769 | Bracket, Roller |
| 65770 | Cylinder Assy, Tail Gate Control Spring |
| 65771 | Yoke, Tail Gate Control Spring Cylinder |
| 65771A | Pin, Tail Gate Control Cylinder Yoke |
| 65780 | Roller Sub-assy |
| 65783 | Rod, Turnbuckle Threaded |
| 65785 | Turnbuckle, Tail Gate Control |
| 65786 | Rod, Tail Gate Control |
| 65787 | Bracket, Return Spring |
| 65788 | Spring, Tail Gate Control Rod Return |
| 65789 | Bolt, Return Spring Eye |
| 65790 | Arm Sub-assy, Roller |
| 65793 | Bracket, Tail Gate Control Hook |
| 65796 | Pin, Tail Gate Control Rod |
| 65797 | Bush, Roller |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
