Toyota Mega Cruiser
1996-10 → 2001-10 · chassis BXD20 · catalogue 851310 · General
Discontinued model
Data version 2002-04
Heating & Air Conditioning - Control & Air Duct
35 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 55084E | Duct Sub-assy, Heater TO Register, NO.1 |
| 55519R | Plate, Heater Control Name |
| 55519S | Label, Rear Cooler Control Information |
| 55707C | Bracket Sub-assy, Cooler Mounting, NO.1 |
| 55707D | Bracket Sub-assy, Cooler Mounting, NO.2 |
| 55761D | Bracket, Heater Mounting |
| 55843A | Duct, Heater TO Register, NO.1 |
| 55844 | Duct, Heater TO Register, NO.2 |
| 55845A | Duct, Heater TO Register, NO.3 |
| 55900A | Control & Accessory Assy, Heater |
| 55905A | Knob, Heater Control |
| 55905B | Knob, Heater Control, NO.2 |
| 55906 | Cable Sub-assy, Heater Control |
| 55906A | Cable Sub-assy, Defroster Damper Control |
| 55907A | Cable Sub-assy, Water Valve Control |
| 55907R | Cable Sub-assy, Temperature Control |
| 55910C | Grommet(FOR HEATER CONTROL CABLE) |
| 55910R | Control Assy, Heater |
| 55922 | Bracket, Heater Control Base |
| 55933A | Clamp, Heater Control Cable |
| 55939 | Ornament, Heater Control |
| 63915 | Duct, Cooler, Inner NO.1 RH |
| 63915A | Duct, Cooler, Inner NO.2 RH |
| 63916 | Duct, Cooler, Inner NO.2 RH |
| 63917 | Duct, Cooler, Inner NO.3 RH |
| 63917A | Duct, Cooler, Inner NO.3 LH |
| 63925 | Duct, Cooler, Inner NO.1 LH |
| 63925A | Duct, Cooler, Inner NO.2 LH |
| 63927A | Cover, Cooler Duct End, NO.1 |
| 63928 | Cover, Cooler Duct End, NO.2 |
| 87212 | Duct, Air, Rear NO.1 |
| 87213 | Duct, Air, Rear NO.2 |
| 87214M | Duct, Heater TO Foot, NO.3 |
| 87226 | Adapter, Air Duct |
| 88890B | Switch Assy, Thermostat |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
