Toyota Raize
2019-10 → present · chassis A200A,A201A,A202A,A210A · catalogue 105110 · Japan
Supported model
Data version 2021-11
Front Seat & Seat Track
78 part groups · 8 illustrations
Part groups
| PNC | Description |
|---|---|
| 71051A | Spring Sub-assy, Front Seat Cushion, RH |
| 71052A | Spring Sub-assy, Front Seat Cushion, LH |
| 71110A | Frame Assy, Front Seat W/Adjuster, RH |
| 71120B | Frame Assy, Front Seat W/Adjuster, LH |
| 71147D | Silencer, Seat Spring, RH(FOR SEATBACK) |
| 71147E | Silencer, Seat Spring, RH(FOR SEAT CUSHION) |
| 71147F | Silencer, Seat Spring, LH(FOR SEATBACK) |
| 71147G | Silencer, Seat Spring, LH(FOR SEAT CUSHION) |
| 71511S | Pad, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71512S | Pad, Front Seat Cushion, LH (FOR SEPARATE TYPE) |
| 71537C | Protector, Front Seat Cushion Edge, RH |
| 71537D | Protector, Front Seat Cushion Edge, LH |
| 71551S | Pad, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71552S | Pad, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71753 | Tray, Front Seat Under |
| 71811D | Shield, Front Seat Cushion, RH |
| 71812D | Shield, Front Seat Cushion, LH |
| 7181C | Ring, Hog, Small (FOR FRONT SEATBACK) |
| 7181CA | Ring, Hog, Small (FOR FRONT SEATBACK) |
| 7181CB | Ring, Hog, Small (FOR FRONT SEAT CUSHION) |
| 7181CC | Ring, Hog, Small (FOR FRONT SEAT CUSHION) |
| 71831B | Cover, Front Seat Hinge, RH |
| 71831D | Cover, Front Seat Hinge, RH |
| 71832B | Cover, Front Seat Hinge, LH |
| 71832C | Cover, Front LH Seat Hinge |
| 71832D | Cover, Front Seat Hinge, LH |
| 71867V | Shield, Front Seat Cushion, Front RH |
| 71876 | Cover, Reclining Adjuster Inside, LH |
| 71910A | Headrest Assy, Front Seat |
| 71910B | Headrest Assy, Front Seat |
| 71930A | Support Assy, Front Seat Headrest |
| 71931D | Support, Front Seat Headrest, RH |
| 71931F | Support, Front Seat Headrest, LH |
| 72110A | Track Assy, Front Seat, Outer RH |
| 72120 | Track Assy, Front Seat, Outer LH |
| 72125S | Cover, Front Seat Track, Upper Rear RH |
| 72125T | Cover, Front Seat Track, Upper Rear LH |
| 72127A | Cover, Seat Track Bracket, Inner Front RH |
| 72128A | Cover, Seat Track Bracket, Inner Front LH |
| 72129 | Protector, Seat Track Lower Rail, NO.1 |
| 72129A | Protector, Seat Track Lower Rail, NO.2 |
| 72129C | Protector, Seat Track Lower Rail, NO.3 |
| 72129D | Protector, Seat Track Lower Rail, NO.4 |
| 72130A | Track Assy, Front Seat, Inner RH |
| 72140A | Track Assy, Front Seat,Inner LH |
| 72157A | Cover, Seat Track Bracket, Inner RH |
| 72158 | Cover, Seat Track Bracket, Inner LH |
| 72211 | Handle, Seat Track Adjusting |
| 72211C | Handle, Seat Track Adjusting |
| 72266 | Cover, Seat Track Upper Rail, LH |
| 72413 | Lever, Vertical Adjuster Lock |
| 72462 | Cover, Vertical Adjuster RH |
| 72525A | Handle, Reclining Adjuster Release, RH |
| 72526A | Handle, Reclining Adjuster Release, LH |
| 72551B | Cover, Reclining Hinge, RH |
| 72552B | Cover, Reclining Hinge, LH |
| 72637F | Spring, Seatback, RH |
| 72637G | Spring, Seatback, LH |
| 72925 | Cover, Front Seat Cushion |
| 72926 | Cover, Front Seat Cushion, NO.1 |
| 72991 | Cover, Front Seat Cushion, RH |
| 72992 | Cover, Front Seat Cushion, LH |
| 72993 | Cover, Front Seatback |
| 72993A | Cover, Front Seatback |
| 72993B | Cover, Front Seatback, RH |
| 72994 | Cover, Front Seatback |
| 72994A | Cover, Front Seatback |
| 72994B | Cover, Front Seatback, LH |
| 73515 | Rail, Front Seat Under Tray, NO.1 |
| 73910A | Airbag Assy, Front Seat, RH |
| 73920A | Airbag Assy, Front Seat, LH |
| 82711H | Clamp, Wiring Harness |
| 87231D | Protector |
| 87268Z | Protector |
| 87510K | Heater Assy, Front Seat Cushion, RH |
| 87510L | Heater Assy, Front Seat Cushion, LH |
| 87510M | Heater Assy, Front Seatback, RH |
| 87510N | Heater Assy, Front Seatback, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
