Toyota Raize
2019-10 → present · chassis A200A,A201A,A202A,A210A · catalogue 105110 · Japan
Supported model
Data version 2021-11
Heating & Air Conditioning - Compressor
12 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 88301 | Rotor Sub-assy, Magnet Clutch |
| 88302B | Stator, Magnet Clutch |
| 88320 | Compressor Assy, Cooler |
| 88329E | Bolt, Compressor, NO.1 |
| 88335 | Gasket Kit, Overhaul |
| 88365 | Ring, Snap |
| 88365A | Ring, Snap (FOR COMPRESSOR) |
| 88370 | Compressor Assy, W/Motor |
| 88403 | Hub Sub-assy, Magnet Clutch |
| 88410 | Clutch Assy, Magnet |
| 88446C | Bolt, Magnet Clutch Setting |
| 88688N | Bracket, Cooler |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
