Toyota Publica
1969-04 → 1988-08 · chassis UP3#,KP3#,50 · catalogue 111110 · Japan
Discontinued model
Data version 1988-12
Meter
26 part groups · 7 illustrations
Part groups
| PNC | Description |
|---|---|
| 83100 | Meter Assy, Combination |
| 83100B | Bulb, Combination Meter, NO.1 |
| 83100G | Glass, Combination Meter |
| 83101 | Socket Sub-assy, Combination Meter Bulb |
| 83102 | Plate Sub-assy, Combination Meter Circuit, NO.1 |
| 83110 | Speedometer Assy |
| 83128 | Knob, Trip Counter |
| 83136 | Glass, Gage Meter |
| 83138 | Glass, Speedometer |
| 83143 | Hood, Combination Meter, Front |
| 83144 | Hood, Combination Meter, Rear |
| 83270 | Tachometer Assy, Engine |
| 83310 | Gage Assy, Fuel Receiver |
| 83400 | Gage Assy, Combination |
| 83400B | Bulb, Combination Gage |
| 83402 | Plate Sub-assy, Combination Gage Circuit |
| 83410 | Gage Assy, Water Temperature Receiver |
| 83510 | Gage Assy, Oil Pressure Receiver |
| 83550 | Gage Assy, ED Monitor |
| 83550A | Hose, ED Monitor Gage |
| 83550B | Union OR Way, ED Monitor Gage |
| 83550V | Valve, Vacuum Transmitting |
| 83610 | Ammeter Assy |
| 83710 | Cable Assy, Speedometer Drive, NO.1 |
| 83910 | Clock Assy |
| 83910B | Bulb, Clock Indicator |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
