Toyota Vitz
2005-01 → 2010-12 · chassis KSP90,NCP9#,SCP90 · catalogue 112120 · Japan
Supported model
Data version 2011-04
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 11415 — Cock Sub-assy, Water Drain(FOR CYLINDER BLOCK) | ||||
| 90910-09107 |
Cock Sub-assy, Water Drain(FOR CYLINDER BLOCK)
2005-01 → 2007-08
ended
|
1NZFE,2NZFE NCP9# | ¥610 | |
| 90910-09107 |
Cock Sub-assy, Water Drain(FOR CYLINDER BLOCK)
2007-08 → 2008-08
ended
|
1NZFE,2NZFE NCP9# F,ILL,U | ¥610 | |
| 90910-09107 |
Cock Sub-assy, Water Drain(FOR CYLINDER BLOCK)
2007-08 → 2008-09
ended
|
1NZFE NCP91 RS | ¥610 | |
| 90910-09107 |
Cock Sub-assy, Water Drain(FOR CYLINDER BLOCK)
2008-08 → 2010-12
ended
|
1NZFE,2NZFE NCP9# | ¥610 | |
| 11415A — Plug, Water Drain Cock(FOR CYLINDER BLOCK) | ||||
| 90910-09087 |
Plug, Water Drain Cock(FOR CYLINDER BLOCK)
2005-01 → 2007-08
ended
|
1NZFE,2NZFE NCP9# | ¥230 | |
| 90910-09116 |
Plug, Water Drain Cock(FOR CYLINDER BLOCK)
2005-01 → 2007-08
ended
|
2SZFE SCP90 | ¥390 | |
| 90910-09087 |
Plug, Water Drain Cock(FOR CYLINDER BLOCK)
2007-08 → 2008-08
ended
|
1NZFE,2NZFE NCP9# F,ILL,U | ¥230 | |
| 90910-09087 |
Plug, Water Drain Cock(FOR CYLINDER BLOCK)
2007-08 → 2008-09
ended
|
1NZFE NCP91 RS | ¥230 | |
| 90910-09116 |
Plug, Water Drain Cock(FOR CYLINDER BLOCK)
2007-08 → 2008-08
ended
|
2SZFE SCP90 F,ILL,U | ¥390 | |
| 90910-09116 |
Plug, Water Drain Cock(FOR CYLINDER BLOCK)
2007-08 → 2008-09
ended
|
2SZFE SCP90 RS | ¥390 | |
| 90910-09087 |
Plug, Water Drain Cock(FOR CYLINDER BLOCK)
2008-08 → 2010-12
ended
|
1NZFE,2NZFE NCP9# | ¥230 | |
| 90910-09116 |
Plug, Water Drain Cock(FOR CYLINDER BLOCK)
2008-08 → 2010-12
ended
|
2SZFE SCP90 | ¥390 | |
| 11434G — Pin, Straight(FOR END PLATE) | ||||
| 90250-10113 |
Pin, Straight(FOR END PLATE)
2005-01 → 2007-08
ended
|
1NZFE,2NZFE NCP9# | ¥120 | |
| 90250-10214 |
Pin, Straight(FOR END PLATE)
2005-01 → 2007-08
ended
|
2SZFE SCP90 | ¥120 | |
| 90250-10214 |
Pin, Straight(FOR END PLATE)
2005-01 → 2005-04
ended
|
1KRFE KSP90 | ¥120 | |
| 90250-10232 |
Pin, Straight(FOR END PLATE)
2005-05 → 2007-08
ended
|
1KRFE KSP90 | ¥100 | |
| 90250-10113 |
Pin, Straight(FOR END PLATE)
2007-08 → 2008-08
ended
|
1NZFE,2NZFE NCP9# F,ILL,U | ¥120 | |
| 90250-10113 |
Pin, Straight(FOR END PLATE)
2007-08 → 2008-09
ended
|
1NZFE NCP91 RS | ¥120 | |
| 90250-10214 |
Pin, Straight(FOR END PLATE)
2007-08 → 2008-08
ended
|
2SZFE SCP90 F,ILL,U | ¥120 | |
| 90250-10214 |
Pin, Straight(FOR END PLATE)
2007-08 → 2008-09
ended
|
2SZFE SCP90 RS | ¥120 | |
| 90250-10232 |
Pin, Straight(FOR END PLATE)
2007-08 → 2008-08
ended
|
1KRFE KSP90 | ¥100 | |
| 90250-10113 |
Pin, Straight(FOR END PLATE)
2008-08 → 2010-12
ended
|
1NZFE,2NZFE NCP9# | ¥120 | |
| 90250-10214 |
Pin, Straight(FOR END PLATE)
2008-08 → 2010-12
ended
|
2SZFE SCP90 | ¥120 | |
| 90250-10232 |
Pin, Straight(FOR END PLATE)
2008-08 → 2010-12
ended
|
1KRFE KSP90 | ¥100 | |
| 11434Y — Pin, Straight(FOR OIL PAN) | ||||
| 90250-08120 |
Pin, Straight(FOR OIL PAN)
2005-01 → 2007-08
ended
|
1NZFE,2NZFE NCP9# | ¥140 | |
| 90250-08120 |
Pin, Straight(FOR OIL PAN)
2007-08 → 2008-08
ended
|
1NZFE,2NZFE NCP9# F,ILL,U | ¥140 | |
| 90250-08120 |
Pin, Straight(FOR OIL PAN)
2007-08 → 2008-09
ended
|
1NZFE NCP91 RS | ¥140 | |
| 90250-08120 |
Pin, Straight(FOR OIL PAN)
2008-08 → 2010-12
ended
|
1NZFE,2NZFE NCP9# | ¥140 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
