Toyota Vitz
2005-01 → 2010-12 · chassis KSP90,NCP9#,SCP90 · catalogue 112120 · Japan
Supported model
Data version 2011-04
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 74221 — Cover, Door Armrest, RH | ||||
| 74221-52010-B0 note |
Cover, Door Armrest, RH
2005-01 → 2007-08
ended
|
KSP90,NCP9#,SCP90 B,F,U,X | ¥3,810 | |
| 74221-52010-B1 note |
Cover, Door Armrest, RH
2005-01 → 2007-08
ended
|
NCP91 RS | ¥3,810 | |
| 74221-52010-E0 note |
Cover, Door Armrest, RH
2005-08 → 2007-08
ended
|
KSP90,NCP9#,SCP90 B,F,ILL,U,X | ¥3,810 | |
| 74221-52010-B0 note |
Cover, Door Armrest, RH
2007-08 → 2008-08
ended
|
KSP90,NCP9#,SCP90 B,F,U | ¥3,810 | |
| 74221-52010-B1 note |
Cover, Door Armrest, RH
2007-08 → 2008-09
ended
|
NCP91,SCP90 RS | ¥3,810 | |
| 74221-52010-E0 note |
Cover, Door Armrest, RH
2007-08 → 2008-08
ended
|
KSP90,NCP9#,SCP90 B,F,ILL,U | ¥3,810 | |
| 74221-52010-B0 note |
Cover, Door Armrest, RH
2008-08 → 2010-12
ended
|
KSP90,NCP9#,SCP90 B,F,U | ¥3,810 | |
| 74221-52010-B1 note |
Cover, Door Armrest, RH
2008-09 → 2010-12
ended
|
NCP91,SCP90 RS | ¥3,810 | |
| 74221-52010-E0 note |
Cover, Door Armrest, RH
2008-08 → 2010-12
ended
|
KSP90,NCP9#,SCP90 B,F,ILL,U | ¥3,810 | |
| 74222 — Cover, Door Armrest, LH | ||||
| 74222-52010-B0 note |
Cover, Door Armrest, LH
2005-01 → 2007-08
ended
|
KSP90,NCP9#,SCP90 B,F,U,X | ¥3,810 | |
| 74222-52010-B1 note |
Cover, Door Armrest, LH
2005-01 → 2007-08
ended
|
NCP91 RS | ¥3,810 | |
| 74222-52010-E0 note |
Cover, Door Armrest, LH
2005-08 → 2007-08
ended
|
KSP90,NCP9#,SCP90 B,F,ILL,U,X | ¥3,810 | |
| 74222-52010-B0 note |
Cover, Door Armrest, LH
2007-08 → 2008-08
ended
|
KSP90,NCP9#,SCP90 B,F,U | ¥3,810 | |
| 74222-52010-B1 note |
Cover, Door Armrest, LH
2007-08 → 2008-09
ended
|
NCP91,SCP90 RS | ¥3,810 | |
| 74222-52010-E0 note |
Cover, Door Armrest, LH
2007-08 → 2008-08
ended
|
KSP90,NCP9#,SCP90 B,F,ILL,U | ¥3,810 | |
| 74222-52010-B0 note |
Cover, Door Armrest, LH
2008-08 → 2010-12
ended
|
KSP90,NCP9#,SCP90 B,F,U | ¥3,810 | |
| 74222-52010-B1 note |
Cover, Door Armrest, LH
2008-09 → 2010-12
ended
|
NCP91,SCP90 RS | ¥3,810 | |
| 74222-52010-E0 note |
Cover, Door Armrest, LH
2008-08 → 2010-12
ended
|
KSP90,NCP9#,SCP90 B,F,ILL,U | ¥3,810 | |
| 74231 — Panel, Front Armrest Base, Upper RH | ||||
| 74231-52290-B0 note |
Panel, Front Armrest Base, Upper RH
2005-01 → 2007-08
ended
|
KSP90,NCP9#,SCP90 B,F,U,X | ¥1,860 | |
| 74231-52290-B1 note |
Panel, Front Armrest Base, Upper RH
2005-01 → 2007-08
ended
|
NCP91 RS | ¥1,860 | |
| 74231-52290-E0 note |
Panel, Front Armrest Base, Upper RH
2005-08 → 2007-08
ended
|
KSP90,NCP9#,SCP90 B,F,ILL,U,X | ¥1,860 | |
| 74231-52290-B0 note |
Panel, Front Armrest Base, Upper RH
2007-08 → 2008-08
ended
|
KSP90,NCP9#,SCP90 B,F,U | ¥1,860 | |
| 74231-52290-B1 note |
Panel, Front Armrest Base, Upper RH
2007-08 → 2008-09
ended
|
NCP91,SCP90 RS | ¥1,860 | |
| 74231-52290-E0 note |
Panel, Front Armrest Base, Upper RH
2007-08 → 2008-08
ended
|
KSP90,NCP9#,SCP90 B,F,ILL,U | ¥1,860 | |
| 74231-52290-B0 note |
Panel, Front Armrest Base, Upper RH
2008-08 → 2010-12
ended
|
KSP90,NCP9#,SCP90 B,F,U | ¥1,860 | |
| 74231-52290-B1 note |
Panel, Front Armrest Base, Upper RH
2008-09 → 2010-12
ended
|
NCP91,SCP90 RS | ¥1,860 | |
| 74231-52290-E0 note |
Panel, Front Armrest Base, Upper RH
2008-08 → 2010-12
ended
|
KSP90,NCP9#,SCP90 B,F,ILL,U | ¥1,860 | |
| 74232 — Panel, Front Armrest Base, Upper LH | ||||
| 74232-52220-B0 note |
Panel, Front Armrest Base, Upper LH
2005-01 → 2007-08
ended
|
KSP90,NCP9#,SCP90 B,F,U,X | ¥2,290 | |
| 74232-52220-B1 note |
Panel, Front Armrest Base, Upper LH
2005-01 → 2007-08
ended
|
NCP91 RS | ¥2,290 | |
| 74232-52220-E0 note |
Panel, Front Armrest Base, Upper LH
2005-08 → 2007-08
ended
|
KSP90,NCP9#,SCP90 B,F,ILL,U,X | ¥2,290 | |
| 74232-52220-B0 note |
Panel, Front Armrest Base, Upper LH
2007-08 → 2008-08
ended
|
KSP90,NCP9#,SCP90 B,F,U | ¥2,290 | |
| 74232-52220-B1 note |
Panel, Front Armrest Base, Upper LH
2007-08 → 2008-09
ended
|
NCP91,SCP90 RS | ¥2,290 | |
| 74232-52220-E0 note |
Panel, Front Armrest Base, Upper LH
2007-08 → 2008-08
ended
|
KSP90,NCP9#,SCP90 B,F,ILL,U | ¥2,290 | |
| 74232-52220-B0 note |
Panel, Front Armrest Base, Upper LH
2008-08 → 2010-12
ended
|
KSP90,NCP9#,SCP90 B,F,U | ¥2,290 | |
| 74232-52220-B1 note |
Panel, Front Armrest Base, Upper LH
2008-09 → 2010-12
ended
|
NCP91,SCP90 RS | ¥2,290 | |
| 74232-52220-E0 note |
Panel, Front Armrest Base, Upper LH
2008-08 → 2010-12
ended
|
KSP90,NCP9#,SCP90 B,F,ILL,U | ¥2,290 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
