Toyota Passo

2016-04 → present · chassis M700A,M710A · catalogue 113140 · Japan

Supported model Data version 2018-10

Floor Side Member

38 part groups · 3 illustrations

PNC	Description
51401C	Bracket Sub-assy, Engine Front Mounting, RH
51403D	Bracket Sub-assy, Engine Rear Mounting
51963G	Hook, Transport, Front RH
51964G	Hook, Transport, Front LH
52141F	Arm, Front Bumper, RH
52142G	Arm, Front Bumper, LH
53213D	Support, Radiator, Upper RH
53214C	Support, Radiator, Upper LH
53653A	Brace, Rear Suspension, Lower RH
53654A	Brace, Rear Suspension, Lower LH
57031A	Reinforce Sub-assy, Front Side Member, NO.2 RH
57032A	Bracket Sub-assy, NO.7 Body Mounting, LH
57069A	Member, Rear Floor, Center
57101	Member Sub-assy, Front Side, RH
57102	Member Sub-assy, Front Side, LH
57111	Member, Front Side, RH
57112	Member, Front Side, LH
57115A	Plate, Front Side Member, Outer RH
57116A	Plate, Front Side Member, Outer LH
57117	Plate Sub-assy, Front Side Member, Front RH
57118	Plate Sub-assy, Front Side Member, Front LH
57181B	Plate, Front Side Member, NO.3 RH
57182B	Plate, Front Side Member, NO.3 LH
57197	Box, Torque, Front RH
57198	Box, Torque, Front LH
57411A	Member, Floor Side, Inner RH
57412A	Member, Floor Side, Inner LH
57601	Member Sub-assy, Rear Floor Side, RH
57602	Member Sub-assy, Rear Floor Side, LH
57605B	Member Sub-assy, Rear Floor Cross, NO.1
57606C	Member Sub-assy, Rear Floor Cross, NO.2
57615A	Member, Rear Floor Side, Rear RH
57616A	Member, Rear Floor Side, Rear LH
57681	Bracket, Rear Shock Absorber, RH
57682	Bracket, Rear Shock Absorber, LH
57776A	Brace, Rear Lower Arm Bracket
57815B	Reinforcement, Belt Anchor, NO.1 RH
57816A	Reinforcement, Belt Anchor, NO.1 LH

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
