Toyota Sienta

2003-09 → 2015-06 · chassis NCP8# · catalogue 119110 · Japan

Supported model Data version 2013-07
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Front Steering Gear & Link

13 part groups · 2 illustrations

Illustrations

Figure 453665D 453665D 2003-09 → — Figure 453666C 453666C 2003-09 → —

Part groups

PNCDescription
44243 Insulator, Power Steering Rack Housing Heat
45046 End Sub-assy, Tie Rod, RH
45047 End Sub-assy, Tie Rod, LH
45319A Insulator, Steering Gear Heat
45503 End Sub-assy, Steering Rack
45510 Gear Assy, Steering
45515 Bracket, Steering Rack Housing, NO.2
45517 Grommet, Steering Rack Housing, NO.2
45535 Boot, Steering Rack, NO.1
45535B Clip(FOR STEERING RACK BOOT)
45535D Clamp(FOR STEERING RACK BOOT NO.1)
45536 Boot, Steering Rack, NO.2
45536A Clamp(FOR STEERING RACK BOOT NO.2)
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
