Toyota Sienta
2003-09 → 2015-06 · chassis NCP8# · catalogue 119110 · Japan
Supported model
Data version 2013-07
Rear Seat & Seat Track
87 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 71236A | Clamp, Rear Seat Cushion Spring |
| 71308E | Leg Sub-assy, Rear Seat, RH |
| 71309C | Leg Sub-assy, Rear Seat, Rear LH |
| 71324J | Cushion, Rear Seat |
| 71324K | Cushion, Rear Seat |
| 71332B | Spacer, Rear Seatback Hinge |
| 71332C | Spacer, Rear Seatback Hinge |
| 71334A | Stopper, Rear Seat Leg |
| 71461A | Spring, Rear Seat Cushion, NO.1 |
| 71462 | Spring, Rear Seat Cushion, NO.2 |
| 71601A | Pad Sub-assy, Rear Seat Cushion W/Cover |
| 71601C | Pad Sub-assy, Rear Seat Cushion W/Cover, RH |
| 71602A | Pad Sub-assy, Rear Seat Cushion W/Cover, LH |
| 71602C | Pad Sub-assy, Rear Seat Cushion W/Cover, LH |
| 71603C | Pad Sub-assy, Rear Seatback W/Cover |
| 71603D | Pad Sub-assy, Rear Seatback W/Cover, RH |
| 71604D | Pad Sub-assy, Rear Seatback W/Cover, LH |
| 71604E | Pad Sub-assy, Rear Seatback W/Cover, LH |
| 71628E | Spacer, Rear Seat Cushion |
| 71691D | Cover, Rear Seat Cushion Hinge, Upper RH |
| 71692D | Cover, Rear Seat Cushion Hinge, Upper LH |
| 71693 | Cover, Rear Seat Cushion Hinge, Lower RH |
| 71694 | Cover, Rear Seat Cushion Hinge, Lower LH |
| 71739 | Cushion, Seat Support |
| 71833A | Cover, Rear Seat Reclining, NO.1 RH |
| 71833C | Cover, Rear Seat Reclining, NO.2 RH |
| 71834A | Cover, Rear Seat Reclining, NO.1 LH |
| 71834B | Cover, Rear Seat Reclining, NO.2 LH |
| 71843A | Cover, Rear Seat Reclining, NO.2 RH |
| 71844A | Cover, Rear Seat Reclining, NO.2 LH |
| 71848B | Cap, Seat Adjuster Cover, RH |
| 71849A | Cap, Seat Adjuster Cover, LH |
| 71875C | Cover, Reclining Adjuster Inside, RH |
| 71876B | Cover, Reclining Adjuster Inside, LH |
| 71878A | Cover, Rear Seat Reclining, Inner RH |
| 71878C | Cover, Rear Seat Reclining, Inner RH |
| 71879A | Cover, Rear Seat Reclining, Inner LH |
| 71879C | Cover, Rear Seat Reclining, Inner LH |
| 71931A | Support, Rear Seat Headrest |
| 71931C | Support Assy, Rear NO.2 Seat Headrest |
| 71940A | Headrest Assy, Rear Seat |
| 71940C | Headrest Assy, Rear NO.1 Seat, RH |
| 71960B | Headrest Assy, Rear Seat, Center |
| 72047 | Cover Sub-assy, RR Seat Track, Inner RH |
| 72048 | Cover Sub-assy, RR Seat Track, Inner LH |
| 72152A | Cover, Rear Seat Track Bracket, Inner |
| 72152B | Cover, Rear Seat Track Bracket, Inner |
| 72159B | Cover, Rear Seat Track Bracket, Outer |
| 72159F | Cover, Rear Seat Track Bracket, RH |
| 72159G | Cover, Rear Seat Track Bracket, LH |
| 72160 | Track Assy, Rear Seat, Outer RH |
| 72170 | Track Assy, Rear Seat, Outer LH |
| 72180C | Track Assy, Rear Seat, Inner RH |
| 72203A | Handle Sub-assy, Rear Seat Track, RH |
| 72203B | Handle Sub-assy, Rear Seat Track, LH |
| 72213A | Knob, Seat Track Adjusting Handle |
| 72249 | Guide, Seat Track Locking |
| 72646 | Grommet, Rear Seatback Stop Button |
| 72661B | Lever, Rear Seatback Rod Control, Outer |
| 72679 | Bezel, Rear Seatback Lock Control |
| 72679B | Bezel, Rear Seatback Lock Control |
| 72695A | Cable, Rear Seat Lock Control |
| 72704A | Cable, Rear Seat Reclining Control |
| 72704B | Cable, Rear Seat Reclining Control, NO.2 |
| 72727B | Knob, Rear Seat Reclining Control Lever, RH |
| 72727C | Knob, Rear Seat Reclining Control Lever, LH |
| 73653 | Cover, Rear Seat Belt Inner Anchor, RH |
| 73654 | Cover, Rear Seat Belt, Inner Anchor, LH |
| 74650E | Strap Assy, Assist, RH |
| 76973E | Cover, Rear Under Side, RH |
| 76974E | Cover, Rear Under Side, LH |
| 78910 | Cable Assy, Fold Seat Lock Control, NO.1 |
| 78920 | Cable Assy, Fold Seat Lock Control, NO.2 |
| 79101 | Frame Sub-assy, NO.1 Seat Cushion |
| 79102 | Frame Sub-assy, NO.1 Seat Cushion, LH |
| 79103A | Frame Sub-assy, NO.1 Seatback, RH |
| 79104 | Frame Sub-assy, NO.1 Seatback, LH |
| 79124 | Stopper, Seat Cushion Leg |
| 79236A | Cover, NO.2 Seat Leg |
| 79246A | Cover, NO.2 Seat Leg, NO.2 |
| 79260 | Spring Assy, NO.2 Seat Cushion |
| 79270A | Spring Assy, NO.2 Seat Cushion, LH |
| 79280 | Spring Assy, NO.2 Seatback |
| 79290A | Spring Assy, NO.2 Seatback, LH |
| 79937 | Cover, Rear Seat Leg, NO.2 |
| 79937A | Cover, Rear Seat Leg, NO.2 |
| 79956 | Cover, Rear Seat Leg Bracket |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
